P-247-006e - 第45页
G -S050-07 1012-003 43 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE N-8 703 6301273686 BRACKET 1→0 For Left-Rear 803N--210-303 21 1F8437 706 6301495941 BRACKET 1 For Left-Rear 803N-A210390-A001 21 1FB277 708…
G -S050-07
0909-002
42
703
739
708
701
706
EXCHANGE
EXCHANGE
For Left-Rear
For Right-Front
多機能ヘッド取付
Main Machine Modification(Left-Rear,Right-Front)
本体対応（左奥、右前）
For Attaching Multi-Functional Head
G -S050-07(GXH-1,1S) G -S050-07(GXH-1,1S)
Fig. N-8
コンベア部 -
NA,NB,NC
シュート１
Conveyor Section-NA,NB,NC Chute 1
G -S050-07
1012-003
43
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
N-8
703 6301273686 BRACKET 1→0 For Left-Rear 803N--210-303 211F8437
706 6301495941 BRACKET 1 For Left-Rear
803N-A210390-A001
211FB277
708 6301495958 BRACKET 1 For Right-Front
803N-A210390-A002
211FB278
739 6301274034 BRACKET 1→0 For Right-Front
803N--210-309
211F8443
G -S050-07
0909-002
44
33
31
32
35
22
14
4
5
EXCHANGE
EXCHANGE
EXCHANGE
EXCHANGE
5
4
14
22
多機能ヘッド取付
Main Machine Modification(Left-Rear,Right-Front)
本体対応（左奥、右前）
For Attaching Multi-Functional Head
G -S050-07(GXH-1,1S) G -S050-07(GXH-1,1S)
Fig. D-1
部品認識部 - 部品認識カメラ
Recognition Section-Recognition Camera
