Chapter 17 Servo Alarm
1. Troubleshooting on Servo Alarm
Alarm
Codes
Contents of
Servo Alarm
Cause and Remedy
A linear servo control error was detected.
(Cause 1) The mounting direction of the linear scale is not
matching.
(Remedy) Check the mounting direction of the linear scale.
Review the settings (Linear Scale Electronic
Gears) of Parameter Nos. 65 and 66.
Check the linear scale control error detection level
+F67.
(Cause 2) The motor worked with Servo ON.
(Remedy) Confirm that the motor has stopped and set
"Servo ON" again.
(Cause 3) Initial Magnetic Pole Detection Not Executed
(Remedy) Execute the initial magnetic pole detection.
42 Linear Servo
Control Error
Detection
(Cause 4) The resolution of the linear scale signal is different from
the specified one.
(Remedy) Review the settings (Linear Scale Electronic
Gears) of Parameter Nos. 65 and 66.
Check how the linear scale is mounted.
Main circuit device overheat
(Cause 1) Servo amplifier faulty.
(Remedy) Change the servo amplifier.
(Cause 2) The power supply was turned on and off
continuously by overloaded status.
(Remedy) Review the drive method.
45 Main circuit
device overheat
(Cause 3) Air cooling fan of servo amplifier stops.
(Remedy 1) Change the servo amplifier or cooling fan.
(Remedy 2) Reduce ambient temperature.
17-19
0506-001
Device
Name
Chip Mounter
Block Name
Page No.
Unit Name
Revision
Model
Item
GXH-1
Chapter 17 Servo Alarm
1. Troubleshooting on Servo Alarm
Alarm
Codes
Contents of
Servo Alarm
Cause and Remedy
Servo motor temperature rise actuated the thermal
protector.
(Cause 1) Ambient temperature of servo motor is over 40°C.
(Remedy) Review environment so that ambient temperature
is 0 to 40°C.
(Cause 2) Servo motor is overloaded.
(Remedy 1) Reduce load.
(Remedy 2) Review operation pattern.
(Remedy 3) Use servo motor that provides larger output.
46 Servo motor
overheat
(Cause 3) Thermal protector in encoder is faulty.
(Remedy) Change servo motor.
Load exceeded overload protection characteristics of servo
amplifier.
Load Factor 300%: 2.5 s or more
Load Factor 200%: 100 s or more
(Cause 1) Servo amplifier is used in excess of its continuous
output current.
(Remedy 1) Reduce load.
(Remedy 2) Review operation pattern.
(Remedy 3) Use servo motor that provides larger output.
50 Overload 1
(Cause 2) Servo system is instable and hunting.
(Remedy 1) Repeat acceleration/deceleration to execute auto
tuning.
(Remedy 2) Change auto tuning response setting.
(Remedy 3) Set auto tuning to OFF and make gain
adjustment manually.
17-20
0506-001
Device
Name
Chip Mounter
Block Name
Page No.
Unit Name
Revision
Model
Item
GXH-1
Chapter 17 Servo Alarm
1. Troubleshooting on Servo Alarm
Alarm
Codes
Contents of
Servo Alarm
Cause and Remedy
(Cause 3) Machine struck something.
(Remedy 1) Review operation pattern.
(Remedy 2) Install limit switches.
(Cause 4) Wrong connection of servo motor.
Servo amplifier
′s output terminals U, V, and W do
not match servo motor
′s input terminals U, V, and
W.
(Remedy) Connect correctly.
(Cause 5) Encoder faulty.
[Checking Method]: When the servo motor shaft is rotated
with the servo off, the cumulative
feedback pulses do not vary in
proportion to the rotary angle of the
shaft but the indication skips or
returns midway.
(Remedy) Change the servo motor.
Machine collision or the like caused max. output current to
flow successively for several seconds.
Servo motor locked: 1s or more
(Cause 1) Machine struck something.
(Remedy 1) Review operation pattern.
(Remedy 2) Install limit switches.
51 Overload 2
(Cause 2) Wrong connection of servo motor
Servo amplifier
′s output terminals U, V, and W do
not match servo motor
′s input terminals U, V, and
W.
(Remedy) Connect correctly.
17-21
