WPC5
Page 19 / 21 16.09.2021
Pos. Item no. Description Part marking
80 03072955-02 WPC5 POWER SUPPLY UNIT SPARE PART
03048169-01 POWER CABLE
03048582-01 LINE FILTER FOR 3-PHASE SYSTEMS
10A
81 03057556-02 TRANSFORMER WPC5 Spare
82 03048357-01 CONTACTOR 3RT10 15-2BM42 Spare Part
83 03048563-01 CONTACTOR 3RT10 15-1BB42 Spare Part
84 03048564-01 AUXIL. SWITCH BLOCK
3RH19/2POLE/1NC+1NO
Spare Part
85 00342396S01 INTERFER. SUPPR. DIODE
F.CONTACT.DC24-70
SPARE PART
86 03048925-01 SUPPRESS. DIODE FOR CONTACTOR
DC150-250V
Spare Part
87 03047752-02 INRUSH-CURRENT LIMITER SPARE PART
88 03048868-01 RECTIFIER BRIDGE 800V / 25A SPARE PART
89 00372649-01 CONTACTOR SAFETY COMBINAT.
3TK2828-1BB41
SPARE PART
97 00323829-01 GROUND TERMINAL BLOCK
4-COND. 280-677
SPARE PART
91 00323828-01 THROUGH TERMINAL BLOCK GY
4-CON. 280-633
SPARE PART
00353338-01 ADJACENT JUMPER 280-402 SPARE PART
00323836-01 END PLATE 2.5MM ORANGE
280-315
00356396-01 SCREWLESS END STOP 6MM
249-116
SPARE PART
03057251-01 CABLE: 24VDC / 30VAC L1-L3 /
35VDC
03072974-01 CABLE: UZK 200V DC
03072975-01 CABLE: CONTROL ON / UZK1+UZK2
ON
03048176-01 CABLE: UNBLOCKING BRAKE
03048574-01 CABLE DUCT 40X40X180
90 03008823-01 CABLE DUCT 40X40MM GY
T1-40X40
03056486-01 BOTTOM PLATE ASSEMBLY
03048588-01 CABLE DUCT 40X60X355
03049187-01 GROUND WIRE (PE2)
00372781-01 FUSE CLAMP-10A (6,3X32) 282-128 SPARE PART
WPC5
Page 20 / 21 16.09.2021
Pos. Item no. Description Part marking
03077196-01 GROUND WIRE (PE1) WPC5
03049183-01 GROUND WIRE (PE3)
03049184-01 GROUND WIRE (PE4)
03049185-01 GROUND WIRE (PE5)
03049186-01 GROUND WIRE (PE6)
03049188-01 GROUND WIRE (PE8)
03051744-01 SNAP FERRITE SLEEVE, D=9.0MM
03072950-01 WPC5 CONTROL UNIT CPL.
03067748S01 WPC5 CONTROL UNIT (BASE) SPARE PART
03067747-01 WPC 5 CONTROL UNIT MECHANICS
03057378-02 WPC - BACK PLANE
92 00305343-01 GUIDE RAIL ES902C 160MM
PLASTIC
SPARE PART
93 00334696-01 GUIDE RAIL 160MM FOR CONTACT
SPRING
SPARE PART
94 00334698-01 CONTACT SPRING FOR GUIDE RAIL SPARE PART
95 00325507-01 SINGLE LOCK BOW
96 00305438-01 FRONT PLATE 6HE 4TECC SPARE PART
03011060-01 PARTIAL FRONT PLATE 6HE 2TE
03071834-01 BACKPLANE COVER
03049711-01 COVER SERVO AMPLIFIERS
03051368-01 FAN ASSEMBLY CONTROL UNIT
03048384-01 FAN CONTROL UNIT
98 00319141-01 AXIAL AIR VENT 4414F 24VDC SPARE PART
03049709-02 GROUND STRAND CONTROL UNIT
99 03071546-01 WPC POWER SUPPLY BOARD SPARE PART
03058447-01 AXIS KSP-A364 ANALOG FOR WPC SPARE PART
03071828-01 AXIS KSP-A364 BASIS CARD FOR
WPC
102 03058447-01 AXIS KSP-A364 ANALOG FOR WPC SPARE PART
103 03057377-02 WPC5 - CONTROLLER BOARD SPARE PART
03077151-01 WPC5 BRAKE RESISTOR
105 00344207-02 BALLAST CIRCUIT BS200/1000 SPARE PART
106 03048005-01 SERVO AMPLIFIER TBS200/3Z1 SPARE PART
107 00344204-04 SERVO AMPLIFIER TBS200/10X-02 SPARE PART
03056927-02 CRASH-LS FEED AXIS TOWER SPARE PART
