KGE_HSDXg_PL - 第9页
2 4 Head Holder Head KGE-081002 2 22 28 19 4 1 3 16 3 16 29 17 30 13 14 25 26 15 1 1 8 7 9 18 10 20 23 23 21 21 1 7 9 16 18 OLD OLD 18 2 5 6 5 6 OLD Fig 1 Fig 2 OLD 6 24 12 5 24 23 No. Part No. Part Name Q'ty Remark…
1
4
Body Head
Head
KGE-1107
51
49
50
48
38
16
53
52
13
18
14
17
15
46
47
3,71,72
4
27
30
29
30
26
28
23
23
24
25
37
39
20
19
22
21
22
36
53
52
45
44
36
6
33
34
35
42
11
39
39
9
43
40
7
10
12
8
5
39
39
68
67
1
31
31
66
32
65
55
57
54
61
56
59
57
60
58
62
63,70
64
73
No.3 Head
2
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV6-M7113-12X NOZZLE 2 SHOT 1608 1 Type111
2 KV6-M7120-10X HEATER UNIT ASSY 1
3 KV6-M7114-01X JOINT,NOZZLE 1 IEI,MUSASHI 30cc,10cc
4 KU4-M7114-00X NUT,NOZZLE 1
5 KV6-M7102-00X PLATE 1,Z AXIS 1
6 KV6-M7103-00X PLATE 2,Z AXIS 1
7 KV6-M7104-00X PLATE 3,Z AXIS 1
8 KV6-M7105-00X GUIDE,LINEAR 1
9 KV6-M7107-00X STOPPER,Z AXIS 1
10 KV6-M7106-00X PLATE 4,Z AXIS 1
11 KV6-M7109-00X BRACKET,LOWER SENSOR 1
12 KV6-M7121-00X PLATE 1,R AXIS 1
13 KV6-M7122-00X HOLDER,BEARING 1
14 KV6-M7123-00X BEARING 1 1
14-1 90990-26J009 BEARING 1 (2007/12/6) MDX0068 OK
15 KV6-M7124-00X PLATE 1,BRG. 1
16 KV6-M7125-02X SHAFT,NOZZLE 1
17 KV6-M7128-01X PULLEY 1,R AXIS 1
18 KV6-M7129-00X BRACKET,ORG.SENSOR 1
19 KV6-M7131-00X SPLINE,BALL 1
20 KV6-M7132-00X SHAFT,R AXIS 1
21 KV6-M7135-00X COLLAR 1,R AXIS 1
21-1 90990-41J051 COLLAR 1 (2008/4/17) ME20197 OK
22 90933-02J625 BEARING 2
23 KV6-M7137-00X BEARING 2,R AXIS 2
23-1 90933-02J689 BEARING 2 (2007/9/24) MD80067 OK
24 KV6-M7138-00X COLLAR 2,R AXIS 1
24-1 90990-41J052 COLLAR 1 (2008/4/17) ME20197 OK
25 KV6-M7139-00X COLLAR 3,R AXIS 1
25-1 90990-41J053 COLLAR 1 (2008/4/17) ME20197 OK
26 KV6-M7141-00X SHAFT 1,TENSION 1
27 KV6-M7143-00X BRACKET,TENSION 1
28 KV6-M7144-00X BELT,R AXIS 1
29 90933-02J106 BEARING 2
30 90933-03J106 BEARING 2
31 KV6-M7147-10X HOLDE 2,BEARING 1
32 KV6-M7168-10X STAY 1,HOLDER 2 1
33 KV6-M7161-00X SHAFT 1,SPRING 1
34 KV6-M7162-00X SPRING,FROATING 1
35 KV7-M8103-00X Z AXIS ASSY 1
36 KV7-M8123-00X COUPLING,MOTOR 2
37 KV7-M8132-00X PULLEY,MOTOR R 1
38 KV6-M7171-A0X VALVE ASSY SPARE 1
38-1 KV6-M7171-106 VALVE ASSY 1 SI 0904001 (2008/10/21) ME90107 NG
39 KM4-M7173-00X LOCATING PIN 7
40 KM1-M7127-00X SPRING POST 1
41
42 KV6-M655B-00X SENSOR,1-2 1
43 KG2-M2284-00X SPG.MAIN 1
44 90K55-4107HA AC SERVO MOTOR 1
45 90K55-4W07HC AC SERVO MOTOR 1
46 90185-06J000 NUT U 1
47 99009-15400 CIRCLIP 1
48 SL10-02 JOINT 1
49 SL8-02 JOINT 1
50 TL4-02 JOINT 1
51 SL4-M5 JOINT 1
52 92907-03200 WASHER,PLAIN 8
53 91317-03005
BOLT HEXAGON,SOCKET HEAD
8
54 92A08-03005 SCREW,SET 2
55
56
95307-06600 NUT HEXAGON 1
57 95307-05600 NUT HEXAGON 3
58 95307-04600 NUT HEXAGON 1
59 91317-05020
BOLT HEXAGON,SOCKET HEAD
1
60 98704-04010 SCREW,FLAT HEAD 2
61 98903-03005 SCREW,BIND HEAD 1
62 KV6-M7190-00X HOLDER,ADAPTA 1
63 KV6-M7172-00X ADAPTA 1 IEI 30cc
64 92A90-03103 SCREW,SET 2
65 KV6-M7169-00X STAY 3,HOLDER 2 1
66 KV6-M7167-00X STAY 2,HOLDER 2
67 KV6-M7181-00X BRKT.1,LVL.SENSOR 1
68 KV6-M7187-00X FIBER 1 FU-66
69
70 KV6-M7172-20X ADAPTA ASSY EFD 30cc 1 EFD MUSASHI 30cc (2002/5/7) M240101
71 KV6-M7114-21X JOINT NOZZLE EFD 30cc 1 EFD 30cc (2003/4/9) M340028
72 KV6-M7114-30X JOINT NOZZLE EFD 10cc 1 EFD 10cc (2003/4/9) M340028
73 KV6-M7157-00X NUT,R MOTOR 1 (2000/3/31) M030175
2
4
Head Holder
Head
KGE-081002
2
22
28
19
4
1
3
16
3
16
29
17
30
13
14
25
26
15
11
8
7
9
18
10
20
23
23
21
21
1
7
9
16
18
OLD
OLD
18
2
5
6
5
6
OLD
Fig 1
Fig 2
OLD
6
24
12
5
24
23
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV6-M7101-03X PLATE 1,HEAD 1
1-1 KV6-M7101-04X PLATE 1,HEAD 1 (2005/6/30) MB60149 NG
2 KV6-M7155-01X COVER 1,CAMERA 1
2-1 KV6-M7155-02X COVER 1,CAMERA 1 (2005/6/30) MB60149 NG
3
KV6-M7151-01X STAY 1,MOTOR
2
4 KV6-M7152-10X PLATE 1,R MOTOR 1
5 KV6-M7154-00X COVER 1,MOTOR 1
5-1 KV6-M7154-01X COVER 1,MOTOR 1 Fig. 1 (2002/11/12) M2X0030 NG
5-2 KV6-M7154-02X COVER 1,MOTOR 1 Fig. 2 (2008/10/21) ME90080 NG
6
KV6-M7153-01X BRACKET 1,VALVE
1
6-1 KV6-M7153-02X BRACKET 1,VALVE 1 Fig. 1 (2002/11/12) M2X0030 NG
6-2 KV6-M7153-03X BRACKET 1,VALVE 1 Fig. 2 (2008/10/21) ME90080 NG
7 KM5-M7185-00X GRIP 1
7-1 KV7-M2256-00X GRIP 1 (2005/7/20) MB70089 NG
8
KV7-M8140-00X STAY, FID. CAMERA 1
9 KM5-M7184-00X SHAFT GRIP 1
9-1 KM5-M7184-10X SHAFT GRIP 1 (2005/7/20) MB70089 NG
10 KV6-M7195-00X STAY ,HANDLE 1
10-1 KV6-M7195-00X STAY,HANDLE 1 (2005/7/20) MB70093 OK
11 KGM-M8141-00X STAY,FID.LIGHT 1
11-1 KV7-M8141-01X STAY,FID.LIGHT 1 (2006/6/19) MC60070 OK
12 KV6-M7183-10X BRKT.3,LVL.SENSOR 1
12-1 KV6-M7183-11X BRKT.3,LVL.SENSOR 1 (2002/5/30) M250070 OK
13 KGA-M7210-01X CCD CAMERA 1
14 KV7-M7211-00X LENS 095 1
15 KV7-M7600-00X FIDUCIAL LIGHT ASSY 1
16 KM4-M7173-00X LOCATING PIN 6
16-1 90990-43J011 PIN 6 (2008/6/3) ME30136 OK
17 KGA-M66F2-00X C. CABLE ASSY 1 L6M
18
99480-04012 PIN,PARALLEL 2
18-1
KM4-M7173-00X LOCATING PIN 2 (2005/6/30) MB60149 NG
18-2 Delete (2006/9/20) MC90066
19 91317-06018 BOLT HEXAGON, SOCKET 4
20 91317-05018 BOLT HEXAGON, SOCKET 3
21 91317-05014 BOLT HEXAGON, SOCKET 8
22 91317-04014 BOLT HEXAGON, SOCKET 4
23 91317-04010 BOLT HEXAGON, SOCKET 12
24 91317-04006 BOLT HEXAGON, SOCKET 9
25 91317-03018 BOLT HEXAGON, SOCKET 2
26 91317-03008 BOLT HEXAGON, SOCKET 4
27
28 KV6-M7156-50X PLATE, CABLE 1
29 KGA-M66F4-00X C. CABLE ASSY 1 1.7M
30 KV7-M7165-00X SEAL DON'T TOUCH 1
1
5
Nozzle Selection
Nozzle
KGE-081002
NOZZLE 2 SHOT 1608
Type 111
NOZZLE 2 SHOT 2125
Type 112
NOZZLE 2 SHOT LARGE
Type 113
NOZZLE 1 SHOT 0.4
Type 114
NOZZLE 1 SHOT 0.8
Type 115
NOZZLE 1 SHOT 1.5
Type 116
NOZZLE 2 SHOT 1608(P0.8)
Type 11A
NOZZLE 1 SHOT 1.0
Type 11B
NOZZLE 1 SHOT 1.3
Type 11C
Nozzle Type
Name
Size
Nozzle Type
Name
Size
Nozzle Type
Name
Size
0.4
2.4
0.4
0.9
0.5
2.4
1.3
0.9
3.2
1.8
1.6
0.8
1.6
1.0
1.6
1.5
1.8
1.3
1.8
0.4
2.4
0.8
NOZZLE LBA (1608 A.P)
Type LBA
NOZZLE LCA (2012 A.P)
Type LCA
0.4
0.4
1.2
0.9
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV6-M7113-12X NOZZLE 2 SHOT 1608 1 Type111
2 KV6-M7113-23X NOZZLE 2 SHOT 2125 1 Type112
3 KV6-M7113-32X NOZZLE 2 SHOT LARGE 1 Type113
4 KV6-M7113-42X NOZZLE 1 SHOT 0.4 1 Type114
5 KV6-M7113-52X NOZZLE 1 SHOT 0.8 1 Type115
6 KV6-M7113-62X NOZZLE 1 SHOT 1.5 1 Type116
7 KV6-M711A-00X NOZZLE 2 SHOT1608(P0.8) 1 Type11A
8 KV6-M711B-00X NOZZLE 1 SHOT 1.0 1 Type11B
9 KV6-M711C-00X NOZZLE 1 SHOT 1.3 1 Type11C
10 KV6-M71LB-A0X NOZZLE LBA (1608A.P) 1 TypeLBA
11 KV6-M71LC-A0X NOZZLE LCA (2012A.P) 1 TypeLCA
