UK= fåíÉêäçÅâë=
There are two types of interlocks used on the=mä~ëã~ä~ÄpóëíÉãNMM; hardware and software.
In all areas, the hardware interlock will override any software interlock. The hardware
interlocks, and their effect on the system components in the case of an interlock becoming
open circuit are as follows:
The electrical interlocks are divided into two circuits controlling the power to the system.
1) The mains power connection is made to a system Power Distribution Unit. The Power
Distribution Unit will disable all of its power outputs under the following conditions:
a) If the Emergency Off button is pressed.
b) If there is an interruption of the power input to the system.
c) If the Power Distribution Unit external facility interlock sensor link becomes
open circuit.
NOTE:
The Power Distribution Unit external facility interlock sensor
link enables the interlocks of external sensors, e.g. gas
detectors, exhaust scrubbers, etc., to be monitored by the Power
Distribution Unit. External interlock contacts connected to this
link should be voltage free and Normally Closed, i.e. faulting to
an Open Circuit.
2) The system internal 24V supply, comprises a process line and a chamber line:
The 24V process line, which controls the process gases and plasma power supply
units, will be disabled under the following conditions:
a) If the Vacuum Safety Switch is open circuit, i.e. Chamber Pressure > 600
mbar.
b) If the load lock slit valve is OPEN.
The 24V chamber line will be disabled under the following conditions, leaving the system
controller operational, but disabling all system components:
a) If the Water Flow switch is not closed.
b) If the Chamber top is OPEN.
Installation Data (ICP 180)
Printed: 22-Mar-06, 6:57 Page 17 of 18 Issue 5: June 05
mä~ëã~ä~ÄpóëíÉãNMM= lñÑçêÇ=fåëíêìãÉåíë=mä~ëã~=qÉÅÜåçäçÖó Installation Data
Emergency Off / Electrical
Fail
24V Process line 24V Chamber line
Interlock Fail Restore Fail Restore Fail Restore
System/Controller OFF Restart
Required
ON
ON
RF Generator OFF Powered, NOT
active
OFF Powered,
NOT active
OFF Powered,
NOT active
Process Gases OFF Powered, NOT
active
OFF Powered,
NOT active
OFF Powered,
NOT active
Automatic
Pressure
Controller Valve
CLOSED
CLOSED
NO
CHANGE
NO
CHANGE
CLOSED
CLOSED
Load lock
Slit Valve
HOLD
HOLD
HOLD
HOLD
HOLD
HOLD
Pumps OFF Pumps must be
restarted
NO
CHANGE
NO
CHANGE
OFF Pumps must
be restarted
Table 2 - Consequences of open circuit interlocks
The other component specific interlocks are incorporated into the software controller,
alerting the operator of conditions such as low process gas flow, pump failure, etc. The
software also monitors the position of the wafer handling mechanisms, ensuring safe
operation.
