INFM0209.D.pdf
1.30 NOT MACHINED .6250 .6245 3.375±.010 TYP 3.375±.010 TYP (1.6875) TYP (.8625) TYP 4.06±.02 SQ 4X 1/4-28 UNF-2B .50 MIN 2.00±.25 TYP .50±.06 TYP 23/26 .560±.015 2.00±.03 8.665 MAX 3.39 MAX .1875/.1855 SQ X 1.12 LONG KE…
1.30
NOT MACHINED
.6250
.6245
3.375±.010
TYP
3.375±.010
TYP
(1.6875)
TYP
(.8625)
TYP
4.06±.02 SQ
4X 1/4-28 UNF-2B
.50
MIN
2.00±.25
TYP
.50±.06
TYP
23/26
.560±.015
2.00±.03
8.665 MAX
3.39 MAX
.1875/.1855 SQ
X 1.12 LONG KEY
3.75
1.66
A
4
B
3
C
D
4
3
2
1
A
B
2
C
D
ANGLES: X°:±3° X.X°:±0.5°
TOLERANCES:.XX:±.01 .XXX:±.005
UNITS ARE IN INCHES [mm]
C
SCALE:
SHEET:
PART NO./REV:
DESCRIPTION:
1/1
GEARMOTOR 33A5BEPM-WX2 -WX3 -WX4
1:2
INFM0209
BODINE ELECTRIC COMPANY
UNLESS OTHERWISE SPECIFIED:
1
D.0
REPRESENTATIVE OF MODEL NUMBER(S):
1050 1052 1054 1056 1058 1060 1062 1064 1066 1068 1070 1072
1200 1202 1204 1206 1208 1210 1212 1214 1216 1218 1220 1222
1247 1248 1249 1250 1251 1252 1253 1254 1255 1256 1257 1259
1150 1152 1153 1154 1158 1162 1164 1166 1168 1169 1170 1172
