User’s Manual Line Computer UNIX 1 Hardware / Software Installation
Software Version 402.xx Edition 06/96 1.2 Hardware Installation
1 - 17
Setting synchronisation
By default, the monitor is set to separate horizontal and vertical synchronisation (Separate/Composite
sync.).
If the monitor is connected to a computer which is not compatible with the industry standard, the
synchronization type may have to be changed.
●
On the first level of the OSD menu select
IS
.
●
Press the CONFIRM button.
The second level of the OSD menu will be displayed.
●
Select
HV
(Seperate/Composite sync.) or
SO
(Sync. On Green).
●
Press the CONFIRM button.
Activating/deactivating Power Management
The monitor’s Power Management can be deactivated.
However, it should as a rule remain active so that you can utilize the monitor’s power-saving mode.
●
Select
IS
(Input Selection).
●
Press the CONFIRM button.
The second level of the OSD menu will be displayed.
●
Select
PS
(Power Saving) or
NO
(No Power Saving).
●
Press the CONFIRM button.
2
IS
HV / SO---------HV
PS / NO---------PS
2
IS
HV / SO---------HV
PS / NO---------PS
1 Hardware / Software Installation User’s Manual Line Computer UNIX
1.2 Hardware Installation Software Version 402.xx Edition 06/96
1 - 18
Activating the factory settings
The factory settings for image size, position, edges, synchronization and Power Management can be
recalled.
●
On the first level of the OSD menu select the symbol
➩➪
(Recall).
●
Press the CONFIRM button.
All aforementioned settings are restored to their preset values.
☞
NOTE
The colors can be restored to their preset values in the
CA
submenu using the symbol
➩➪
(Recall
Color) .
☞
NOTE
If you use a different monitor type than the one described in sections 1.2.3, 1.2.4 and 1.2.5, please refer to
the manual supplied with your monitor for details on connections and setting possibilities.
User’s Manual Line Computer UNIX 1 Hardware / Software Installation
Software Version 402.xx Edition 06/96 1.2 Hardware Installation
1 - 19
1.2.5.2 Cleaning the Monitor
-
The monitor should only be cleaned in the switched off condition using a soft cloth.
-
The interior of the cabinet may only be opened and cleaned by a service technician.
●
Prior to cleaning disconnect plug from UPS.
●
Wipe monitor enclosure using a soft cloth.
In the case of persistent stains, moisten cloth with a mild cleaning agent.
●
Clean screen using a soft, non-linting cotton cloth or lens tissue.
CAUTION
∆
!
- No cleaning sprays, wax or compressed air are to be used on the enclosure (see also instructions
supplied with the monitor).
- Ensure that no alcohol comes into contact with the enclosure.
- Never use any strong solvents such as thinners or benzine or abrasive cleaning agents as these
would cause damage to the enclosure.
- When cleaning the monitor with a moist cloth it must be ensured that no moisture can enter the
interior of the cabinet.
- Do not place any objects onto the unit.
- Be sure that the ventilation louvers are not covered.
