NOTE
Only in cases where a second LAN card for the SIPLACE LAN is installed in the line computer, will
the IP address, netmask and broadcast address of the LAN card for the SIPLACE LAN be displayed
together with an inquiry as to whether they are to be changed.
●
Enter
y
and press RETURN if the data are to be changed.
Enter internet address for SIPLACE network card
(<Return> for default....):
●
Enter the address and press RETURN.
The entry is displayed.
Is the internet address ’...’ correct [y/n]:
●
Enter
y
and press RETURN if the entry is correct.
(Enter
n
and press RETURN if the entry needs to be corrected).
Enter netmask for SIPLACE network card
(<Return> for default....):
●
Enter the number of the "netmask" and press RETURN.
The entry is displayed.
Is the netmask ’...’ correct [y/n]:
●
Enter
y
and press RETURN if the entry is correct.
(Enter
n
and press RETURN if the entry needs to be corrected).
Enter broadcast address for SIPLACE network card
(<Return> for default....):
●
Enter the number of the "broadcast address" and press RETURN.
The entry is displayed.
Is the broadcast address ’...’ correct [y/n]:
●
Enter
y
and press RETURN if the entry is correct.
(Enter
n
and press RETURN if the entry needs to be corrected).
The entry of
y
completes the configuration of the LAN card.
User’s Manual Line Computer UNIX 1 Hardware / Software Installation
Software Version 402.xx Edition 06/96 1.3 Software Installation
1 - 29
A note is now displayed on the handling regarding OEM software, as well as the steps to be per-
formed following the start of the LC program (consistency check via Data Manager of stations and
setups and line configuration).
●
Read the messages and acknowledge them by pressing any key.
After a short time a message is displayed on the screen requesting you to reboot the system.
** Safe to Power Off **
- or -
** Press Any Key to Reboot **
●
Remove streaming tape and press any key on the keyboard.
The computer system reboots and after a while, the "Login" dialog box (see chap. 2, section 2.2.1)
appears.
●
Typ e
plr
in the "..... login" editing field and press the RETURN key twice.
The LC software is started with the selected desktop configuration and language.
ATTENTION
∆
!
After any
initial installation
of the LC software has been carried out, it is mandatory that following
start-up of the line computer the stations be configured with the aid of the Configuration Editor (see
chapt. 12) before proceeding further. Subsequently, the line must be configured with the aid of the Line
Editor (see chap. 12).
Whenever an
Update
or
Upgrade
of the LC software is performed, it is absolutely necessary that
after the software has been started up, first the stations and subsequently all set-ups be checked for
consistency using the "Consistency Checker" (see chapter 4).
After the consistency check has been completed, the stations must be compiled using the "Compiler
for stations" (see chapter 4).
