18 Appendix User’s Manual Line Computer UNIX
18.1 General Specifications Concerning LC Data Software Version 402.xx Edition 06/96
18 - 4
18.1.4 Allocation Package Form Numbers, Adhesive Patterns and Dispense Settings
Package Form Designation GF No.
Adhesive
Pattern
Dispense
Setting
0402 100 1 1
0603 102 1 2
0805 103 1 4
1206 105 1 9
1210 106 1 9
1812 110 1 12
2010 111 1 14
2220 112 1 14
DPACK, T0252 404 1 9
DIL4 570
DIL6 571
DIL8 572
DO214_AA, SOD6 421
DO214_AB, SOD15 422
DO214_AC 420
ECS14*6.25*7 360
ECV A d3*h5.7 340
ECV B d4*h5.7 341
ECV C d5*h5.7 342
ECV D d6.3*h5.7 343
ECV d8*h6.5 351
ECV d8*h10.6 350
ECV d10.2*h10.5 352
KALIB_01_4x4_080894 1
KALIB_02_SO20 2
KALIB_03_SO14 3
KALIB_11_PLCC68 11
KALIB10 176 COPLAN 10
KALIB10 60 COPLAN 12
Ceramic resonator 1200 1 12
MAXIMELF 202 1 20
User’s Manual Line Computer UNIX 18 Appendix
Software Version 402.xx Edition 06/96 18.1 General Specifications Concerning LC Data
18 - 5
MAXIMELF_diode 205 1 20
Melf_Diode_small_thick_SOD87 204 1 9
MICROMELF 200 1 7
MINIMELF 201 1 9
MINIMELF_DIODE_SOD80 203 1 9
PLCC18R/11.75*8.15 708
PLCC18R/13.45*8.25 709
PLCC20 700 8 18
PLCC22R 710
PLCC28 701 8 18
PLCC28R 711
PLCC32R 712
PLCC44 702 15 18
PLCC52 703 15 18
PLCC68 704 15 18
PLCC84 705
PLCC100 706
PLCC124 707
QFP44_1.0 900
QFP60Ru_1.0 970
QFP64R_1.0 903
QFP80R_1.0 913
QFP100_0.3 960
QFP100B_25mil 933
QFP100R_0.65 922
QFP120_0.8 916
QFP128_0.8 917
QFP132B_25mil 934
QFP160_0.65 924
QFP164B_25mil 935
QFP196B_25mil 936
QFP208_0.5 945
QFP240_0.5 946
Package Form Designation GF No.
Adhesive
Pattern
Dispense
Setting
18 Appendix User’s Manual Line Computer UNIX
18.1 General Specifications Concerning LC Data Software Version 402.xx Edition 06/96
18 - 6
QFP256_0.4 953
SO6 501 1 18
SO8 502 1 18
SO8_high_OK8 582 1 18
SO8L 506 1 18
SO14 504 1 18
SO14L 508 2 18
SO16 505 3 18
SO16L 509 3 18
SO18L 510 3 18
SO20L 511 3 18
SO24L 512 4 18
SO28L 513 7 18
Sockel_PLCC28_Methode 719
Sockel_PLCC32_Methode 720
Sockel_PLCC44_Methode 721
Sockel_PLCC52_Methode 722
Sockel_PLCC68_Methode 723
Sockel_PLCC84_Methode 724
Sockel_PLCC28_AMP 729
Sockel_PLCC32_AMP 730
Sockel_PLCC44_AMP 731
Sockel_PLCC52_AMP 732
Sockel_PLCC64_AMP 733
Sockel_PLCC48_AMP 734
SOD6, DO214_AA 421
SOD15, DO214_AB 422
SOD80 203 1 9
SOD87 204 1 9
SOD123 410 1 9
SOD323 411 1 9
SOJ24 /b8.6 800 1 18
SOJ26 /b8.6 801 1 18
Package Form Designation GF No.
Adhesive
Pattern
Dispense
Setting
