PCB Vacuum
PCB Support
KGY-081209
6
12
Option (PCB Vacuum, PCB Support)
Conveyor
10
11
2
7
8
4
8
9
8
15
19
45
16
17
18
48
48
20
52
46
51
53
31
44
27
32
29
28
49
32
47
27
36
35
49
23
38
23
50
49
36
35
49
36
40
35
34
23
21
22
25
27
26
29
28
49
23
26
44
23
24
30
33
38
39
13
14
3
9
12
43
42
41
6
1
6
6
5
PCB Vacuum
PCB Support
No. Part No. Part Name Q'ty Remarks Rank Level No. Part No. Part Name Q'ty Remarks Rank Level
1 KV8-M9213-00X EJECTOR 1 A
39 KGY-M3306-00X SUPPORT 05 ASSY 1 /
2 KGY-M653M-00X
SENSOR,PCB VCM
1
B ×
40 KGY-M3316-00X
BLOCK 05 1
/
3 KV8-M9212-00X VALVE 1 B × 41 KV8-M9213-A0X SPARE FILTER 1 E
4 KGR-M9933-00X INLINE FILTER 2 A
42 KGR-M9933-F0X FILTER,SPARE 1 E
5 KG2-M8582-40X VALVE 1 B
43 91317-04050 BOLT HEX.SOCKET HEAD 2 M4X50
6 $SL8-02 JOINT 4 / × 44 91317-04045 BOLT HEX.SOCKET HEAD 2 M4X45
7 $SL10-02 JOINT 2 /
45 91317-04025 BOLT HEX.SOCKET HEAD 2 M4X25
8 $ULA10 JOINT 5 /
46 91317-04020 BOLT HEX.SOCKET HEAD 2 M4X20
9 $USD10-8 JOINT 2 /
47 91317-04014 BOLT HEX.SOCKET HEAD 2 M4X15
10 $ULAD8-6 JOINT 1 /
48 91317-03008 BOLT HEX.SOCKET HEAD 6 M3X8
11 $UT8 JOINT 1 /
49 91317-03006 BOLT HEX.SOCKET HEAD 20 M3X6
12 $UP8 JOINT 1 /
50 98702-04008 SCREW,FLAT HEAD (+) 2
13 $KM-23 MUFFLER 1 / × 51 92907-04600 WASHER PLAIN 2
14 $SL4-01 JOINT 1 / × 52 99480-05010 PIN,PARALLEL 1
15 KGY-M94A2-00X BLOCK,SUPPORT 2 / × 53 99480-06012 PIN,PARALLEL 1
16 KGY-M94A3-00X VACUUM PAD 1 A
54
17 KGY-M94A5-00X VACUUM PAD 2 A
55
18 KGY-M94A8-00X DOG 2 /
56
19 90990-29J014 SHIM 10 / × 57
20 KGY-M3301-00X SUPPORT 38 ASSY 1 /
58
21 KGY-M3311-00X BLOCK 38 1 /
59
22 90990-41J089 COLLAR 2 /
60
23 K98-M9213-10X MAGNET 8 /
61
24 KGY-M3302-00X SUPPORT 50 ASSY 5 /
62
25 KGY-M3312-00X BLOCK 50 1 /
63
26 90990-41J090 COLLAR 4 /
64
27 KGY-M3331-00X PLATE, MAGNET 5 /
65
28 KGY-M3342-00X PLATE 1, LOCK 3 /
66
29 KGY-M3343-00X PLATE 1, SIM 3 /
67
30 KGY-M3303-00X SUPPORT 30 ASSY 1 /
68
31 KGY-M3313-00X BLOCK 30 1 /
69
32 90990-41J091 COLLAR 4 /
70
33 KGY-M3304-00X SUPPORT 20 ASSY 1 /
71
34 KGY-M3314-00X BLOCK 20 1 /
72
35 KGY-M3344-00X PLATE 2, LOCK 6 /
73
36 KGY-M3345-00X PLATE 2, SIM 6 /
74
37 KGY-M3305-00X SUPPORT 10 ASSY 1 /
75
38 KGY-M3315-00X BLOCK 10 1 /
76
KGY-081209
