4 Placement Functions User Manual SIPLACE S-23 HM 4.3 Feeders Software Version SR.406.xx 02/00 US E dition 152

User Manual SIPLACE S-23 HM 4 Placement Functions

Software Version SR.406.xx 02/00 US Edition 4.3 Feeders

151

4.3.3.1 Meaning of the Entries in the Table for the Linear Feeder

– Loc.

Number of the location

– Track

Number of the track

– Div.

Number of the feeder division

– Tray

This column is irrelevant when setting up the locations of a SIPLACE HS-50.

(Only valid for automatic machines with wafflepack changers)

– CmpName

Name of the component

– Vibrate

If the "<==" symbol is displayed in this column, then this means that the linear feeder on the

corresponding track is currently being vibrated.

4.3.3.2 Vibrate Track With Linear Feeder

Å Select the entry in the table for the track with the linear feeder that has been refilled and that

is to be vibrated now.

The selected line is highlighted in light blue in the table. The "Vibrate on" button is active.

Å Click on the Vibrate on button.

The components used to refill the track are vibrated to the front.

The "Vibrate off" button is active.

Å Click on the Vibrate off button when the vibrating is to be switched off.

Vibration stops.

NOTE

If the user interface is switched to a different view, then vibration will also stop. 4

4 Placement Functions User Manual SIPLACE S-23 HM

4.3 Feeders Software Version SR.406.xx 02/00 US Edition

152

User Manual SIPLACE S-23 HM 5 Single Functions

Software Version SR.406.xx 02/00 US Edition 5.1 General comments

153

5 Single Functions

5.1 General comments

Gantry functions and transport functions are known as single functions. They are used to set up

and test the machines and to carry out particular actions following a machine shutdown caused

by an error.

Single functions can be used to control various function modules in a defined manner.

WARNING

Single functions may only be executed by appropriately qualified and trained personnel, since

improper handling can result in personal injury/damage to the machine.
