7 What should you do ... User Manual SIPLACE S-23 HM

7.2 Switching off the SIPLACE line Software Version SR.406.xx 02/00 US Edition

324

7.2 Switching off the SIPLACE line

ATTENTION

Before you switch off the line, ALWAYS make sure that:

– All placement operations on the stations are completed.

– The z-axis of all placement heads are in the top end position.

– None of the placement heads still contain components.

– All gantries have moved into the standby position.

– The station computers have been properly shut down.

7.2.1 Switching off the line computer

CAUTION

NEVER just switch off the line computer on the power switch (of the UPS).

ALWAYS shut down the operating system of the line computer with "Shutdown". Otherwise you

will almost certainly lose a lot of data and may need to reinstall the line computer software.

Å Position the mouse at the right or lower edge of the screen.

The cursor will change into a cross.

Å Press and hold down the left mouse button. The main menu appears.

Å Move the mouse cursor onto the ’Shutdown’ menu item and then release the mouse button.

The following dialog box appears on screen:

Å Click on yes. The dialog box closes and the operating system shuts down. This operation takes

around 1 minute. The following then appears:

Å Switch off the UPS.

really shutdown?

yes no

** Safe to Power Off **

-or-

** Press Any Key to Reboot **

User Manual SIPLACE S-23 HM 7 What should you do ...

Software Version SR.406.xx 02/00 US Edition 7.2 Switching off the SIPLACE line

325

7.2.2 Switching off the stations

ATTENTION

NEVER switch off the station during operation using just the main switch except in an emergency.

Shut down the operating system of the station with "Shut down computer..." before you switch off

the station. If you switch off the station during operation without properly shutting down the oper-

ating system beforehand, then the station computer may not start up the next time the station is

switched on. 7

Proceed as follows to switch off the station: 7

Å Terminate all placement operations.

Å Check to make sure that the z-axes of all placement heads are in the upper end position.

Å Check to see if there are still components in the placement heads and remove any components

found.

Å If necessary, move all gantries to the standby position with the help of the corresponding gantry

functions (see chapter 5, section 5.2.2.1).

NOTE

All gantries are normally moved to the standby position automatically. 7

Å Click on the menu function Shut down computer... in the Operation menu.

All station computer processes are terminated. After the operating system has shut down, a

message will appear on the screen stating that the computer can now be switched off.

Å Now switch off the station on the main switch.

7 What should you do ... User Manual SIPLACE S-23 HM

7.3 Changing jobs Software Version SR.406.xx 02/00 US Edition

326

7.3 Changing jobs

Å Interrupt the job defined for the station on the line computer using the function (Interrupt).

Å Enter the new job on the line computer using the function (Schedule).

Å Check the width of the conveyor belt.

Å Check the position of the magnetic supports and make sure that they cannot collide with com-

ponents on the bottom of the PCB.

Å Carry out the set-up check.

Make sure that the feeder modules are equipped with the correct components and that the

feeder modules are at the correct locations.

Å Check the nozzle configuration in the nozzle changer.

If no nozzle changer is installed, then you must change the nozzles manually.

NOTE

If you change the nozzle manually, ALWAYS make sure that you are using the correct nozzle

type and that the nozzle is seated correctly on the spindle. (The plunger pin must click into

place in the notch slot of the nozzle).

If you have not inserted a nozzle or have used the wrong nozzle type, then the station com-

puter program will prompt you to move the placement head to the service position and

change the nozzle. This error message will also appear if you have not inserted the nozzle

correctly.

If you insert the wrong nozzle or use the wrong nozzle type again, then the gantry will move to

the service position once more after the reference sequence. The station computer program

will continue to prompt for a nozzle change until you have obtained the correct configuration.

If you do not succeed, then proceed as follows:

Å Switch off the station and cancel the specified job on the line computer.

Å Rectify the nozzle error and restart the station.
