User Manual SIPLACE S-23 HM 13 Software Installation
Software Version SR.406.xx 02/00 US Edition 13.1 General definitions
439
13 Software Installation
13.1 General definitions
13.1.1 Initial installation
This is the term used to describe the first time the station software is installed on the computer
system of the SIPLACE S-23 HM. During this installation, sample machine data is installed on the
station computer’s hard disk in addition to the individual "SC" (station computer) and "MC"
(machine controller) software components. 13
13.1.2 Update
If an initial installation has already been performed and a more recent release of the station
software has to be installed, this is known as an "update". When an update is performed, the
stored machine data is not overwritten!
The release is identified by the last two digits of the software version designation.
Example
SR.406.01 SR = system component 406 = version number 01 = release
(station computer)
NOTE
Software versions with recent releases are debugged versions.
They are NOT functionally different from software versions with older releases and are generally
compatible with them.
13 Software Installation User Manual SIPLACE S-23 HM
13.2 Installation of the 406.xx station software Software Version SR.406.xx 02/00 US Edition
440
13.1.3 Upgrade
The installation of a software version with a higher version number than an already installed
software version is known as an "upgrade".
When an upgrade is performed, the machine data is retained and automatically converted to the
new data format if necessary.
The functionality of the station software is identified by the three-digit number (version number)
of the complete software version designation.
Example
SR.406.xx 406 = version number This identifies the functionality of the software.
13.2 Installation of the 406.xx station software
For the procedure for the installation of the station software, please refer to the software version
description for the corresponding version. 13
NOTE
The software version description is supplied with the software package for the station software.13
13
13.3 Installation of the software for "Remote Service"
(option)
For the procedure for the installation of the "ReachOut" software which is used for the "Remote
Service", please refer to the software version description for the corresponding version. 13
NOTE
The software version description is supplied with the software package for the "ReachOut"
software. 13
13
