2 Operational Safety User Manual SIPLACE S-23 HM
2.1 Safety instructions Software Version SR.406.xx 02/00 US Edition
64
2
2
2
2
2
2
2
2
Item 4 in Fig. 2.1 - 4 showing the warning
signs on the basic machine - NAFTA region 2
2
2
2
2
2
2
2
2
2
2
2
Item 5 in Fig. 2.1 - 4 showing the warning signs on the basic
machine - NAFTA region - visible when the covers are open 2
2
User Manual SIPLACE S-23 HM 2 Operational Safety
Software Version SR.406.xx 02/00 US Edition 2.1 Safety instructions
65
2.1.7 Safety instructions for the PCB barcode reader (option)
Fig. 2.1 - 5 PCB barcode reader (bottom)
(1) PCB barcode reader (bottom)
(2) ‘Laser radiation…’ label (see Fig. 2.1 - 6)
(3) ‘Caution …’ label (see Fig. 2.1 - 7)
CAUTION 2
The scanning beam of the barcode reader has a radiant power of less than 1 mW. The barcode
reader thus conforms to laser class 2 and, according to EN 60825-1, requires no special safety
devices or protective measures. NEVER look into the laser beam. There is also a safety circuit
that switches off the laser diode if the polygon wheel is stationary or rotating too slowly. 2
2
2 Operational Safety User Manual SIPLACE S-23 HM
2.1 Safety instructions Software Version SR.406.xx 02/00 US Edition
66
Laser radiation 2
The radiation from the laser diode (infrared or IR
light) of the PCB barcode reader is harmful to the hu-
man eye, 2
Åso you should never look into the laser beam.
ÅNever direct the PCB barcode reader into other
people’s eyes,
ÅWhen installing the barcode reader, make sure
that the laser beam cannot be not reflected dur-
ing use.
If you open the housing during use, the scanning cy-
cle will continue and the laser diode will continue to
switch on. 2
The laser beam output at the barcode template win-
dow does not exceed 1.0 mW. The PCB barcode
reader thus conforms to protection class 2. 2
Fig. 2.1 - 6 ‘Laser radiation’ label
2
2
2
2
2
2
Fig. 2.1 - 7 ‘Caution …’ label
2
LASER RADIATION
DO NOT LOOK INTO BEAM
CLASS 2 LASER PRODUCT
EN 60825 1991
Max. output radiation: 1.0 mW
Emitted wave length: 670 nm
ATTENTION
Caution
Laser radiation when the cover is opened
and the safety interlock is bypassed
Do not look into the beam
