5 Placement Heads
5.3 Twin Head
Technical Training SIPLACE TX-Series 10/2016 151
5.3.8.6 Pick Up Problem (High Reject Rate)
5.3.8.7 Placement Quality Issue
5 Placement Heads
5.3 Twin Head
152 Technical Training SIPLACE TX-Series 10/2016
5.3.9 Maintenance
Maintenance task Twin Interval Equipment required
Cleaning the pneumatic rotary axis Workflow 4
●
Electronic screwdriver, Phillips
●
SIPLACE cleaning-tissue
●
Isopropanol
●
Multipette
●
Combitips advanced 0,1ml black
●
Klueberalfa DH 3-100, 50ml black
●
Interflon Fin Super (Aerosol)
●
Cleaning Sticks
●
Compressed Air
●
Cleaning wipe, KM-wipe
Cleaning the Z Axis linear guidance Workflow 4
●
Cleaning Sticks
Removing and mounting the PRV Workflow 4
●
Torque screwdriver ESD 1,0-5,0Nm
●
Hexagon socket head cap screwdriver
●
Torque allen swap blade 3mm
Replacing the filter and cleaning the
nozzle seating
Workflow 4
●
Point Pliers 140mm Oval
●
Cleaning wipe, KM-wipe
●
Interflon Fin Super (Aerosol)
Cleaning the Z Axis linear scale Workflow 4
●
Cleaning wipe, KM-wipe
●
Isopropanol
Maintain the PRV Workflow 4
●
Torque screwdriver ESD 0,1-0,6Nm
●
Wrench socket size 8-1/4"
●
POINT PLIERS 140mm OVAL
●
Screwdriver flathead
●
Indented cross blade PH1
●
O-Ring I3601 B-1,5X1,08-N-NBR70
●
Cleaning wipe, KM-wipe
●
Isopropanol
●
ISOFLEX Topas 5051 50ml (green)
●
Compressed air
●
Cleaning sticks
For detailed information refer to the maintenance manual placement head.
5.3.10 Excercise: Twin Head
1. Which description is wrong?
A C&P20 P, CPP and Twin Head can be configured in TX machines.
B Vacuum pump is standard configuration for holding circuit vacuum of C&P20 P.
C Both Twin head and C&P20 P can be configured in a TX2 machine.
D Both pickup and holding circuit vacuum is supplied by the PRV for Twin Head.
2. Twin-Head: Force sensor use for normal placement force 2N, current sensor use for
decrease and increase placement force.
True …………………………………………………………………………………………………
False …………………………………………………………………………………………………
5 Placement Heads
5.3 Twin Head
Technical Training SIPLACE TX-Series 10/2016 153
Room for Your Sketches and Notes
