6 Component Supply
6.8 Analysis - Common Error List
Technical Training SIPLACE TX-Series 10/2016 165
6.8 Analysis - Common Error List
Code Error Description Possible Cause Action
35410
35411
35412
35413
●
Left cutter not retracted
●
Left cutter not extended
●
Right cutter not retracted
●
Right cutter not extended
●
Incorrect proximity
switch position
●
Defective proximity
switch
●
Defective valve
●
Short of compressed
air
●
Defective cylinder
●
Check & adjust the
position of proximity
switch
●
Replace the switch
if necessary
●
Check power &
functionality of the
valve
●
Check compressed
air supply
●
Replace defective
cylinder
34946
34874
31820
35005
●
Stepping of feeder is not
possible
●
Feeder: tape drive error
●
Component was not trans-
ported into the specified
position
●
Tape is jammed or
twisted
●
Tape drive is faulty
●
Toothed wheel is
jammed
●
Check tape feeder
●
Replace the tape
drive or the feeder
●
Check the toothed
wheel and remove
any components
35401 Tape obstructed in tape duct or
couldn’t be cut
●
Stick tape material
used
●
Incorrect position of
cutter blade
●
Worn cutter blade
●
Check tape
stickiness
●
Test different
component tape for
cutting
●
Replace cutter
blade if necessary
30551
30552
●
Cannot open nozzle changer
●
Cannot closed nozzle
changer
●
Nozzle inserted incor-
rectly
●
Components in
nozzle changer
●
Check nozzle
changer for incor-
rect inserted nozzle
or components
Use station software to
check function
6.9 Excercise: Component Supply
1. Which of the following statements is true regarding the TX component supply?
A The component table can be used on SX4 or XS machine.
B Additional retrofitting is necessary for second level reel support.
C The tape waste bin is an industry standard box.
D The use of a JTF-ML is possible on both location1 and 2.
2. Location 1, track 13-1, 2X8mm feeder, the chip component cannot be pick up, please
list possible reason.
………………………………………………………………………………………………………
………………………………………………………………………………………………………
………………………………………………………………………………………………………
………………………………………………………………………………………………………
