9 Control and Communication

9.11 Analysis - Common Error List

230 Technical Training SIPLACE TX-Series 10/2016

9.11 Analysis - Common Error List

Code Error Description Possible Cause Action

30447

30451

30456

30256

30262

●

Communication on GCU-

GCU fast drive bus

interrupted

●

Specified CAN bus is

switched off

●

Secondary CAN bus is off

●

Cannot initialize CAN

hardware

●

Cannot initialize CAN

interface

●

Problem with cable

connection

●

Problem with CIN

●

Problem with certain

content/board in the

CAN circuit

●

Defective MGCU

●

Defect adapter/HCU

●

Check cable

connection

●

Restart the

machine

●

Check the status

and switch setting

on the CIN

●

Check and

redownload

firmware of the

CAN interface

●

Check status /

indication on the

board related in

CAN circuit

●

Check status /

indication of

MGCU/HMCU

●

Replace adapter/

HCU

37752

●

The LED test of the

camera illumination failed

●

No image captured from

camera

●

Power for illumination

of camera failed

●

LED failed but camera

can be operated

●

Problem with camera

GigE

●

Problem of cable GigE

●

Check relevant

circuit of power for

illumination

●

Check output

relevant power

supply (PS)

●

Check the

functionality of

camera

●

Check connection

of the GigE cable

33378

33520

33606

33331

●

Camera cannot be

addressed

●

Board camera cannot be

addressed

●

Image capture from

camera canceled

●

Signal path between

PC and camera inter-

rupted

●

Problem with camera

●

Check cable

connection on

BoxPc

●

Check the coax

cable connection

and trailing cable

connector

●

Check the camera

cable

●

Check the camera

and replace if

necessary

30365

30572

●

Moving the axis is not

permitted, Z Axis is not in

a safe position

●

Incorrect time sequence

when moving Star and Z

Axis

●

Sporadic communica-

tion error for axis con-

trol sequence

●

Permitted overlap

region of Star and Z

been reached

●

Perform head axis

reference run

●

Check the head

and axis

●

Perform overall

reference run

●

If certain segment

defective, replace it

9 Control and Communication

9.12 Excercise: Control and Communication

Technical Training SIPLACE TX-Series 10/2016 231

9.12 Excercise: Control and Communication

1. Which of the following statements is true regarding TX communication system?

A CIN Box is instead of communication board (CAN bus card).

B Vision GigE system is instead of vision hotlink system.

C There are three different bus systems, CAN bus, Gantry CAN bus and FDB.

D All of the above.

2. Which parts do not communicate with the BOXPC via the CAN bus system in TX?

A CIN-Box.

B Conveyor controller (TSP).

C FCU (Feeder control unit), MHCU and MGCU.

D I/O unit (input/ output module).

3. Which of the following statements is true regarding parts exchange?

A No setting required after exchanging a MGCU.

B No setting required after exchanging a MHCU.

C No setting required after exchanging a FCU.

D No setting required after exchanging a CIN-Box.

4. CIN-Box is connected to BoxPC with CAT5 cable, and uses CAN bus cable to

communicate with subsystem.

True …………………………………………………………………………………………………

False …………………………………………………………………………………………………

5. List all of subsystems which are controlled by CAN bus.

………………………………………………………………………………………………………

6. List the parts which are controlled by FCU.

………………………………………………………………………………………………………
