5 Placement Heads 5.1 CPP Head 86 Technical Training SIPLACE TX-Series 10/2016 Maintenance task Multistar CPP Interval Equipment required Oiling the DP Driver Bearing Workflow 3 ● Multipette M4 ● Combitips advanced 0,1m…

5 Placement Heads

5.1 CPP Head

Technical Training SIPLACE TX-Series 10/2016 85

5.1.9.2 CPP Head - Maintenance

Maintenance task Multistar CPP Interval Equipment required

Replacing the Pressure Control Valve Workflow 3

●

Torque screwdriver ESD 0,4 – 1,0Nm

●

Torque allen swap blade 2mm

●

Torque allen swap blade 3mm

Check/replace the silencer Workflow 3

●

Silencer CPP

Cleaning the Holding Circuit Housing Workflow 3

●

Anti-static tweezers, Bernstein 5-192

●

Gasket Kit Retaining Circle/CPP

●

Cleaning sticks

●

Cleaning wipe, KM-wipe

Replacing the O-Rings Holding Circuit Workflow 3

●

Double wrenches size 17x19

●

Torque screwdriver ESD 0,1-0,6Nm

●

Torque allen swap blade 1,5mm

Cleaning the Screwed Joint Workflow 3

●

Anti-static tweezers Bernstein 5-192

●

Gasket Kit Retaining Circle/CPP

●

Cleaning wipe, KM-wipe

Only required for heads with service

hole at the inside of the front plate

Workflow 3

●

Multipette M4

●

Combitips advanced 0,1ml yellow

●

Cleaning wipe, KM-wipe

●

Klueberoil GEM 1 220N 50ml (yellow)

Oiling the Z Axis Linear Guide Workflow 3

●

Multipette M4

●

Combitips advanced 0,1ml blue

●

Torque screwdriver ESD 0,4-1,0Nm

●

Torque allen swap blade 2mm

●

Cleaning wipe, KM-wipe

●

Lubcon Thermoplex ALN 1001/00,

50ml (blue)

●

Cleaning sticks

Checking/Replacing the DP Vacuum

Hoses

Workflow 3

●

Point Pliers 140mm oval

●

Hose Dp / CPP 12x

Cleaning the Light Barrier on the DP

Drive

Workflow 3

●

Anti-static tweezers

●

Bernstein 5-192

●

Isopropanol

●

Cleaning sticks

●

SM Role labels 9x5 black flat

Oiling the DP Segment Guide Workflow 3

●

Multipette M4

●

Combitips advanced 0,1ml blue

●

Cleaning wipe, KM-wipe

●

Lubcon Thermoplex ALN 1001/00,

50ml (blue)

●

Cleaning sticks

5 Placement Heads

5.1 CPP Head

86 Technical Training SIPLACE TX-Series 10/2016

Maintenance task Multistar CPP Interval Equipment required

Oiling the DP Driver Bearing Workflow 3

●

Multipette M4

●

Combitips advanced 0,1ml black

●

Cleaning wipe, KM-wipe

●

Klueberalfa DH 3-100, 50ml (black)

●

Cleaning sticks

Maintain the holding circuit Workflow 3

●

Multipette M4

●

Combitips advanced 10ml orange

●

Cleaning wipe, KM-wipe

●

Ultrasound device FA Bandelin 327

●

Ultrasonic Cleanser Alsar 25 NKF

●

Deionized distilled water

●

Compressed air

Maintain the PRV Workflow 3

●

Torque screwdriver ESD 0,1-0,6Nm

●

Wrench socket size 8-1/4"

●

POINT PLIERS 140mm OVAL

●

Screwdriver flathead

●

Indented cross blade PH1

●

O-Ring I3601 B-1,5X1,08-N-NBR70

●

Cleaning wipe, KM-wipe

●

Isopropanol

●

ISOFLEX Topas 5051 50ml ((green)

●

Compressed air

●

Cleaning sticks

Replacing the Filter Disks Workflow 3

●

Tweezers for filterdisc CPP

●

Filter disc cpl./CPP

Oiling the Star Bearing Workflow 3

●

Hexagon socket head CAP

screwdriver

●

Multipette M4

●

Combitips advanced 0,1ml green

●

Lubric.application tool star bearing

CPP

●

Cleaning wipe, KM-wipe

●

ISOFLEX Topas 5051 50ml ((green)

Cleaning the Component Sensor Workflow 3

●

Component-Sensor protectiv cover/

CPP

●

Isopropanol

●

Cleaning sticks

For detailed information refer to the maintenance Job Cards for the CPP Head.

5 Placement Heads

5.1 CPP Head

Technical Training SIPLACE TX-Series 10/2016 87

5.1.10 Excercise: CPP Head

1. Which of the following is false regarding CPP Head?

A Three placement modes possible: Collect & Place, Pick & Place and Mixed mode.

B With top placement performance the CPP_H: max. components height is 11.5mm and the

CPP_L: max. height components is 6 mm.

C The bottom light sensor is integrated into each DP driver for CPP.

D Holding circuit vacuum is always activated during placement.

2. Which description is correct regarding the CPP Head vacuum system?

A Vacuum pump is a standard component for holding circuit of CPP.

B Pressure Regulator Valve (PRV) supplies the pickup/placement and holding circuit with

vacuum/air kiss during the pickup/placement process.

C The holding circuit vacuum can be switch on/off by the valve block.

D All vacuum values can be measure by PRV.

3. One Base Adapter C&P board is used for CPP, and another Base Adapter with same

part no. is used for C&P20 P, nothing is required to be done if we exchange them.

True …………………………………………………………………………………………………

False …………………………………………………………………………………………………

4. What is the function of component sensor?

………………………………………………………………………………………………………
