Test Research, Inc. TR7600 SII I Series User G uide – Maintenance 7 1.7 Left Side View of the System Figure 7: Left Side View 1) Left Modu le Board Box 2) Left Gate 3) Emergency Stop 4) Adjustable Co mputer Table Lock
Test Research, Inc.
6 TR7600 SIII Series User Guide – Maintenance
1.5 Upper X-Y Table
Figure 5: Upper X-Y Table
1) X Axis 4) Y Axis Support Track
2) X Axis Support Track 5) Z Axis
3) Y Axis 6) X-Ray Tube
1.6 Lower X-Y Table
Figure 6: Lower the X-Y Table
1) Y Axis 4) X Axis Support Track
2) Y Axis Support Track 5) Z Axis
3)
X
Axis
6)
Camera Sets
Test Research, Inc.
TR7600 SIII Series User Guide – Maintenance 7
1.7 Left Side View of the System
Figure 7: Left Side View
1) Left Module Board Box
2) Left Gate
3) Emergency Stop
4) Adjustable Computer Table Lock
Test Research, Inc.
8 TR7600 SIII Series User Guide – Maintenance
1.8 Right Side View of the System
Figure 8: Right Side View
1) Right Module Board Box
2) Emergency Stop
3) Right Gate
