Test Research, Inc.
TR7600 SIII Series User Guide – Maintenance 49
11 S
PARE
P
ARTS
L
IST
Test Research, Inc. Updated Date : 2018/08/06
No. Part number Part Name
Specification and
Description
Picture Quantity
1 32000000330 T5 Fluorescent Lamp 14W 6500K
1
2 81400000026 Lamp/Warning Light E50-RYGZ-24-T25-L
1
Test Research, Inc.
50 TR7600 SIII Series User Guide – Maintenance
3 81000000185 SW Safety Door Switch LS-S02-ZB, MOELLER
1
4 8100000334 SW Photoelectric Switch FU-77
1
5 8100000335 SW Photoelectric Switch FU-77
1
Test Research, Inc.
TR7600 SIII Series User Guide – Maintenance 51
6 80800000091 RELAY 55.32.9.024.0040, 24V DIP FINDER RELAY
1
7 80800000088 RELAY AP5222F 24V DIP PANASONIC RELAY
1
8 20507803302 PCB Board 7600-033-2 MODULE BOARD
1
