Test Research, Inc. TR7600 SIII Series User Guid e – Maintenance 55 17 821400001 00 PCI DSP M ASTER CON TROL CARD SYN-TEK P CIE-L132- HSCT2 1 18 821400001 01 X64 XCEL ERA-CL PX4 DUAL BASE FRAME GR ABBER OR- X4C0-XPD00 1 …
Test Research, Inc.
54 TR7600 SIII Series User Guide – Maintenance
14 31510000075 Camera
CAMERA MODULE
C10650-526 (Note:
Hamamatsu Camera,
20K)
1
15 8179030000182 Conveyor Belt (W=14 T=1.2 L=3495)
2
16 8179030000183 Timing Belt PG-8YU-3440-8
1
Test Research, Inc.
TR7600 SIII Series User Guide – Maintenance 55
17 82140000100
PCI DSP MASTER CONTROL
CARD
SYN-TEK PCIE-L132-
HSCT2
1
18 82140000101
X64 XCELERA-CL PX4 DUAL
BASE
FRAME GRABBER OR-
X4C0-XPD00
1
19 81300008378 TTL TO LVDS MULTI-TRIGGER DB-TTL-TO-LVDS-03
1
Test Research, Inc.
56 TR7600 SIII Series User Guide – Maintenance
20 82100000234 RAM 16GB DDR3 1600 ECC+REG
KINGSTON
KVR16R11D4/16
2
21 82100000306 HARD DISK 1TB SATAIII 3.5Inch 7200RPM WD1003FBYZ
1
22 81600000272 POWER SUPPLY PSM-5860V
SWITCHING POWER
(BPSM086V020)
1
