Test Research, Inc.
TR7600 SIII Series User Guide – Maintenance 57
23 82100000260 PC MOTHER BOARD SUPERMICRO X9DAi
1
24 82140000081 4 PORT RS-232 PCI EXPRESS SUNIX SER6456A
1
25 20507803103 X-RAY Display-1 Backlight Board 7600-031-3
4
Test Research, Inc.
58 TR7600 SIII Series User Guide – Maintenance
26 20507803202 X-RAY display-2 Backlight Board 7600-032-2
1
27 20507806004 LIGHTING CONTROL BOARD Lighting board
1
28
82140000021
phase out
82140000073
DSP SLAVE MODULE
(Mitsubishi )
106-M181-PMA (FOR XY
AXIS)
3
Test Research, Inc.
TR7600 SIII Series User Guide – Maintenance 59
28_1 82140000118 DSP SLAVE MODULE (Yaskawa)
SYN-TEK 106-M191-
YS5T0
3
29 81600000161 X-Ray Tube Power Supply X-Ray Tube Power Supply
1
30 81000000313
LASER DISTANCE SENSOR
(Laser Module)
IL-S065+IL-1000+OP-
87056
3
