PCB barcode scanner Q [mm] 2D topside 310 1D topside 310 2D underside 310 1D underside 310 PCB barcode sc anner L [mm] 1D topside 240 - 310 1D underside 280 - 350 PCB barcode scanner LQ [mm] RQ [mm] 2D topside 3 3 1D top…

100%1 / 272
PCB barcode scanner LQ [mm] RQ [mm]
2D topside 3 3
1D topside 3 3
2D underside 5 5
1D underside 5 5
PCB dimensions/conveyor LO [mm] RO [mm]
SC: 460 mm 3 35
SC: 508 mm 3 61
DC1: 216 mm 3 40
DC1: 2x250 mm 3 66
DC2: 216 mm 3 3
DC2: 2x250 mm 3 3
1 D PCB barcode scanner topside
PCB dimensions/conveyor LU [mm] RU [mm]
SC: 460 mm 35 5
SC: 508 mm 61 5
DC1: 216 mm 15 5
DC1: 2x250 mm 15 5
DC2: 216 mm 40 5
DC2: 2x250 mm 66 5
1D PCB barcode scanner underside
SC Single conveyor
DC1 Dual conveyor, track 1
DC2 Dual conveyor, track 2
SIPLACE 2 PCB barcode scanner assembly instructions
10/2009 Edition 2.3 Restrictions
143
2
2
2
2
2
2.3.4 SIPLACE HS-60 / D4 / D1 / D2
Label dimensions
Stroke width (W): 0.19 < W ≤ 0.3 mm (corresponds to high and
medium density), stroke length:
≥ 4 mm, length of the barcode
template window: ≤ 90 mm
Recommended label color
Coding: black, dark green, dark blue, background: white, beige,
yellow, orange (contrast ratio > 70% as per DIN 66236
Code types
Code 39, Code 128 / EAN 128, Codabar, 2/5 IATA 2/5 industrial,
2/5 interleaved, UPC, EAN, Pharma Code, EAN Addendum
(others available upon request),
up to 25 digits, a barcode filter can also be defined
Laser scanner safety
Laser diode 670 nm (red) / 1.2 mW
Laser protection class 2, type
of protection IP65
2
PCB barcode scanner Q [mm]
2D topside 310
1D topside 310
2D underside 310
1D underside 310
PCB barcode scanner L [mm]
1D topside 240 - 310
1D underside 280 - 350
PCB barcode scanner LQ [mm] RQ [mm]
2D topside 3 3
1D topside 3 3
2D underside 5 5
1D underside 5 5
PCB dimensions/conveyor LO [mm] RO [mm]
SC: 460 mm 3 35
SC: 508 mm 3 61
DC1: 216 mm 3 40
DC1: 2x250 mm, SM1: 430 mm 3 66
DC2: 216 mm 3 3
DC2: 2x250 mm, SM2: 430 mm 3 3
1 D PCB barcode scanner topside
PCB dimensions/conveyor LU [mm] RU [mm]
SC: 460 mm 35 5
SC: 508 mm 61 5
DC1: 216 mm 15 5
DC1: 2x250 mm, SM1: 430 mm 15 5
DC2: 216 mm 40 5
DC2: 2x250 mm, SM2: 430 mm 66 5
1D PCB barcode scanner underside
SC Single conveyor
DC1 Dual conveyor, track 1
DC2 Dual conveyor, track 2
SM1 Dual conveyor in Single conveyor mode, track 1
SM2 Dual conveyor in Single conveyor mode, track 2
2 PCB barcode scanner assembly instructions SIPLACE
2.3 Restrictions 10/2009 Edition
144
2
2
2
2
2
2
2
2
2
SIPLACE 2 PCB barcode scanner assembly instructions
10/2009 Edition 2.3 Restrictions
145
2.3.5 SIPLACE HF series / X-series / D3
SIPLACE HF/X series restrictions (1D scanner,
beam across direction of travel, 2D scanner)
Left
2D topside:
left/right, 3 mm
1D topside:
left/right, 3 mm
2D underside:
left/right, 5 mm
1D underside:
left/right, 5 mm
Right
2D topside, 390 mm
1D topside, 390 mm
2D underside, 430 mm
1D underside, 430 mm
SIPLACE HF/X series
mechanical restrictions
Right
1D topside, 320-350 mm
1D underside, 380-410 mm
1D topside (beam along the
direction of travel:
- Track 1, standard SC, 18":
20 mm right / 3 mm left
- Track 1, optional SC, 20":
44 mm right / 3 mm left
- Track 1, standard DC, 8.5"
24 mm right / 3 mm left
- Track 1, 2x250/1x450 mm DC:
58 mm right / 3 mm left
- Track 2, standard DC, 8.5":
3 mm right / 3 mm left
- Track 2, 2x250/1x450mm" DC:
3 mm right / 3 mm left
1D underside (beam along the
direction of travel:
- Track 1, standard SC, 18":
3 mm right / 20 mm left
- Track 1, optional SC, 20":
3 mm right / 44 mm left
- Track 1, standard DC, 8.5"
3 mm right / 3 mm left
- Track 1, 2x250/1x450 mm DC:
3 mm right / 3 mm left
- Track 2, standard DC, 8.5":
3 mm right / 24 mm left
- Track 2, 2x250/1x450mm" DC:
3 mm right / 58 mm left
Left
