10
Condenso series
CondensoXC
Optimal results with the smallest footprint
The CondensoXC is a space-saving, powerful system for
laboratory applications, small series production and proto-
typing. Exact proling by means of the injection principle and
the option of soldering under an inert atmosphere provides
the optimal soldering results. Void-free soldering can also be
carried out easily with the vacuum option, which increases
the reliability of assemblies signicantly.
With a footprint of just 2.3 m², this system is specially de-
signed for small series and is also ideal for prototype produc-
tion. As a batch system, it can be used flexibly, irrespective of
the production environment.
Stable process for reliable results
Process chamber for a maximum assembly size of 500 x 540 mm (W x L)
Camera for process observation (optional)
Patentierted injektion prinziple
Vacuum process (optional)
11
Loading Concept
The possibilities of CondensoXC
Handling
Gentle cooling
Front loading with pre-assembled product carriers
The CondensoXC is manually loaded with pre-as-
sembled product carriers from the front on the
operator’s side. In this way, the assemblies can
be easily placed on and removed from the inter-
changeable product carriers. The product carrier
is on a rail system to ensure full access to the
working area. Assemblies up to 500 x 540 mm
(W x L) can be placed on the product carriers.
Gentle cooling processes by convection
After the soldering process, the assembly is
cooled by convection to the required temperature.
After cooling the bulkhead opens automatically
and the product carrier can be completely pulled
out on a rail for easy unloading. In addition, a
water-cooled cooling zone is optionally available
to enhance the cooling capacity.
3.
1. 4.
2.
1. Loading
2. Soldering/Vacuum
3. Cooling
4. Unloading
cooling
gentle
12
Condenso series
CondensoXS smart
Safe process due to injection
Depending on the choice of basic model, the CondensoXS
smart can be loaded and unloaded manually or automatical-
ly. With both models, loading is carried out with pre-loaded
product carriers that can hold assemblies up to 650 x 650
mm (W x L). In the case of manual loading, the product
carriers are inserted from the side and removed in the same
way. With the automated model, a handling device can be
tted to the infeed for automatic loading. On the operator’s
side, there is also the option to position the assemblies
on the product carrier or remove them from it when it has
already been inserted.
Flexible cooling options, a vacuum and the injection prin-
ciple also ensure reliable processes with this model in a
partially automated production environment with a medi-
um-size production volume.
Manual or alternatively automatic loading
Flexible cooling inside and outside the process chamber (within optional)
Process chamber for a maximum assembly size of 650 x 650 mm
MES and traceability solutions (optional)
Touch user interface
