22
Accurate proling capability
3 steps to a prole – 5 steps with vacuum
5 steps with vacuum
A pre-vacuum doesn’t just allow the Galden
®
steam to be evenly
injected, it also enables solvents and moisture to be de-gassed
from the solder paste. After the max. soldering temperature has
been reached, the gases that are still present can escape from
the solder paste more easily using an end vacuum. Surface
binding of up to 99 % occurs as a result.
1. Pre-vacuum | Uniform distribution of the Galden
®
2. Injection of the Galden
®
| Pre-heating of the PCB
3. Injection of the Galden
®
| Ideal soldering temperature
4. Vacuum during the melting phase | Void-free solder joint
5. Exhaust of the Galden
®
| Cooling
This makes proling simple! With the Rehm Condenso series,
you only need three steps to create an optimum prole for your
assembly. What’s more, the possibilities are endless for further
rening and adjusting your prole, depending on your require-
ments. However, the following steps are usually enough to
reach the optimum temperature prole for your application:
1. Injection of the Galden
®
| Pre-heating of the PCB
2. Injection of the Galden
®
| Ideal soldering temperature
3. Exhaust of Galden
®
| Cooling
Only 3 steps to a prole
Injection 1 Injection 2 Exhaust/Cooling
3 steps to a prole
Tliq
(217°)
3
2
1
Injection 2 Exhaust/Cooling
5 steps to a prole
Vacuum
(Pre-/ End vacuum)
1
2
3
4
5
Tliq
(217°)
Condenso series | Software
23
The WPS 2.4 is a brand-new, wireless measuring system
which is used to continuously control the temperature
prole. It consists of a sensor with antennas, as well as a
wireless and evaluation unit. The temperature sensor is
directly attached to the workpiece carrier. It works passively
and doesn’t require an external energy supply. A complete
soldering prole can be determined and transferred to the
system software in real-time, without any annoying cables
or batteries. Software-aided documentation and evaluation
functions (Rehm Recorder) allows for a new, complete
traceability level.
› 100 % process monitoring
› Simple, continuous proof of quality
› Stable sensor function without cables or a battery
Workpiece carrier with temperature sensor in loading position
WPS 2.4 – Wireless Proling System
›
Optimal process control with the ViCON Condenso
›
Traceability of all process-relevant data
›
Process monitoring via WPS 2.4 and a Rehm Recorder
›
Reliable process documentation and maintenance history
›
Connection to a superordinate Manufacturing Management System (MES)
All Condenso systems are tted with the Rehm
recorder. The documentation tool replaces exter-
nal temperature recorders and records relevant
process data such as temperature and pressure.
Data collection and traceability are carried out
at an unprecedented level – without having to
interrupt production. This is how soldering proles
are accurately recorded and can be called up and
reproduced every time by series production. The
measured values can be shown graphically with
the Rehm recorder and can therefore also be
documented and compared.
Rehm Recorder
Condenso series | Software
