6.4 Dip Switch Content List
SERVICE MANUAL
SPF
6.4−1
D54SEC−85−020−B0
6.4 Dip Switch Content List
D54SEC−85−020−B0
Sentence No.
(1) MMC, DIP−SW1
SW No.
Functions ON OFF
Standard
setting
1 RAM clear Valid Invalid OFF
2 Not used OFF
3 Not used OFF
4 Not used OFF
5 Not used OFF
6 Not used OFF
7 Not used OFF
8 Not used OFF
DIP−SW2
SW No.
Functions ON OFF
Standard
setting
1 Not used OFF
2 Not used OFF
3 Not used OFF
4 Not used OFF
5 Automatic width control Valid Invalid OFF
6 Maintenance switch Valid Invalid ON
7 Not used OFF
8 ROM ® RAM copy Valid Invalid ON
DIP−SW3
SW No.
Functions ON OFF
Standard
setting
1
EP
ROM
capacity
selection
Refer
to
table
A
OFF
2
EP
ROM
capac
it
yse
l
ec
ti
on
R
e
f
er
t
o
t
a
bl
e
A
OFF
3 Watchdog timer Valid Invalid OFF
4 Not used OFF
Table A
SW No.
Functions
1 2
F
unc
ti
ons
OFF OFF 1M
OFF ON 2M
ON ON 4M
SPF
6.4 Dip Switch Content List
SERVICE MANUAL
6.4−2
D54SEC−85−020−B0
(2) MMI, DIP−SW1
SW No.
Functions ON OFF
Standard
setting
1 Not used Not used Not used OFF
2 Display Liquid crystal CRT ON
3 Not used Not used Not used OFF
4 Not used Not used Not used OFF
5 Password function Valid Invalid OFF
6 FD format IBM NEC OFF
7 RAM boot Valid Invalid OFF
8 Bus access Master Slave OFF
(3) SC, DIP−SW1
SW No.
Functions ON OFF
Standard
setting
1 Compile selection EP.ROM F.ROM ON
2 OFF
3
Mode selection Refer to table B
OFF
4 OFF
Table B
No.
Functions
2 3 4
F
unc
ti
ons
OFF OFF OFF Standard
ON OFF OFF Hard timer 1msec
OFF ON OFF Not defined
ON ON OFF Not defined
OFF OFF ON Not defined
ON OFF ON Not defined
OFF ON ON Not defined
ON ON ON Not defined
6.4 Dip Switch Content List
SERVICE MANUAL
SPF
6.4−3
D54SEC−85−020−B0
DIP−SW2
SW No.
Functions ON OFF
Standard
setting
1 Operation mode selection Refer to table C Regular start up OFF
2 Option 5 Option 1 OFF
3
Division
compile
designation
Option 6 Option 2 OFF
4
Di
v
i
s
i
on comp
il
e
d
es
i
gna
ti
on
Option 7 Option 3 OFF
5 Option 8 Option 4 OFF
6 OFF
7
Division compile designation Refer to table D
OFF
8
p
g
OFF
Table D
No.
Functions
6 7 8
F
unc
ti
ons
OFF OFF OFF Division compile Invalid
ON OFF OFF Select special specification 1
OFF ON OFF Select special specification 2
ON ON OFF Select special specification 3
OFF OFF ON Select special specification 4
ON OFF ON Select special specification 5
OFF ON ON Select special specification 6
ON ON ON Select 2−port RAM (Select from MMC)
Table C
No.
Functions
1 2 3 4 5 6 7 8
F
unc
ti
ons
ON OFF OFF OFF OFF ON ON ON Self check
ON ON ON ON ON ON ON ON System download
DIP−SW3
SW No.
Functions ON OFF
Standard
setting
1 Optical loop 0 error interrupt Valid Invalid OFF
2 Optical loop 1 error interrupt Valid Invalid OFF
3 Optical loop 2 error interrupt Valid Invalid OFF
4 Optical loop 3 error interrupt Valid Invalid OFF
5 Wired subcontroller error interrupt Valid Invalid OFF
6 Not used OFF
7 Not used OFF
8 EP. ROM capacity 1M 256k OFF
