SPF 6.7 Secret Screen Service Functions (CONFIDENTIAL) SERVICE MANUAL 6.7−18 D54SEC−85−080−A0 PRESS TO SELECT PCB CAMERA, TO SCREEN CAMERA. MANUAL : 1BLOCK <<MACHINE INITIAL SETTING>> XXXX−XX−XX XX:XX F1 F2 F…
6.7 Secret Screen Service Functions (CONFIDENTIAL)
SERVICE MANUAL
SPF
6.7−17
D54SEC−85−080−A0
MANUAL : 1BLOCK
<<MACHINE INITIAL SETTING>>
XXXX−XX−XX XX : XX
F1
F2
F3 F4 F5
F6
F7 F8
[RECOGNITION SERVICE]
COMPLETE
X AXIS
Y AXIS
F1
PCB CAMERA
F2
RING
LIGHT TYPE
CAMERA
LIGHT
SELECT
MOVE A POINTER WHERE YOU WANT TO DISPLAY BRIGHTNESS USING
PRESS TO X−AXIS, TO Y−AXIS.
POINTER COORDINATE X : 256
Y : 240
Figure 6.7−16−Recognition service screen
Parameter explanation
· This is a designation of where to display the brightness distribution.
F1 : Brightness distribution of X axis is appears.
F2 : Brightness distribution of Y axis is appears.
F7 : The light is exchanged.
F8 : The screen returns to the upper level.
SPF
6.7 Secret Screen Service Functions (CONFIDENTIAL)
SERVICE MANUAL
6.7−18
D54SEC−85−080−A0
PRESS TO SELECT PCB CAMERA, TO SCREEN CAMERA.
MANUAL : 1BLOCK
<<MACHINE INITIAL SETTING>> XXXX−XX−XX XX:XX
F1
F2
F3 F4 F5
F6
F7 F8
[CAMERA BRIGHT CHECK]
COMPLETE
PCB CAMERA
SCREEN
CAMERA
F1
PCB CAMERA
F2
F4
CAMERA
BRIGHT
CHECK
WINDOW
SHIFT
WINDOW
LS
LIGHT
SELECT
F6
F5
WINDOW SHIFT
RING
WINDOW
LIGHT TYPE
MOVE A WINDOW WHERE YOU WANT TO CHECK BRIGHTNESS USING
AND PRESS TO CHECK BRIGHTNESS.
Figure 6.7−17−Camera brightness check screen
Parameter explanation
· This is a designation of which camera is used and where to move the window when checking the
brightness.
F1 : PCB camera is used.
F2 : Screen camera is used.
F4 : Brightness check is executed.
F5 : Window size (large or small) is selected.
F6 : Window is shifted.
F7 : The light is exchanged.
F8 : The screen returns to the upper level.
6.7 Secret Screen Service Functions (CONFIDENTIAL)
SERVICE MANUAL
SPF
6.7−19
D54SEC−85−080−A0
6.7.10 Approving
MANUAL : 1BLOCK
<<MACHINE INITIAL SETTING>>
XXXX−XX−XX XX:XX
F1
F2 F3 F4 F5 F6
F7 F8
[APPROVING]
EXIT
SELECT FUNCTION USING F KEYS.
F 1 SCREEN MARK APPROVING
F 2 PCB. MARK APPROVING
F3
PCB. MARK / PCB. ADJUST
S MARK
APPROVE
P MARK
APPROVE
(PCB ADJUSTING)
(REPEAT ADJUSTING)
REPEAT
APPROVE
Figure 6.7−18−Approving screen
Parameter explanation
Approving
· This is a designation of which function keys to execute upon the selection.
F1 : Carry out the screen mark certification.
F2 : Carry out the PCB mark certification.
F3 : Carry out the PCB mark and PCB proscription certification.
F8 : Setting is completed.
