15 5. Conveyor Section 5-2. Front-R (Stopper) No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati. 1 LE3-M9001-00X PLATE, FC 1 2 LE3-M9002-00X PLATE, FL 1 3 LG7-M9003-00X PLATE, FR 1 4 LE3-M9004-0…
14
5. Conveyor Section
5-2. Front-R (Stopper)
1
2
3
10
12
11
32
13
14
23
22
18
20
17
15
16
25
24
26
33
28
9
7
8
4
6
29
30
27
31
5
19
21
1
2
3
10
12
11
32
13
14
23
22
18
20
17
15
16
25
24
26
33
28
9
7
8
4
6
29
30
27
31
5
19
21
15
5. Conveyor Section
5-2. Front-R (Stopper)
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1
LE3-M9001-00X PLATE, FC
1
2
LE3-M9002-00X PLATE, FL
1
3 LG7-M9003-00X PLATE, FR 1
4 LE3-M9004-00X PLATE, RC 1
5 LE3-M9005-00X PLATE, RL 1
6 LG7-M9006-00X PLATE, RR 1
7 LG7-M900H-00X SHAFT, DRIVE 1
8 LE3-M900N-00X PLATE, PULLEY 1
9 LE3-M900T-00X BRACKET (L) 1
10 LE3-M900U-00X BRACKET (R) 1
11 LG7-M900J-00X PULLEY, DRIVE F 1
12 LE3-M900L-00X BRKT. MOTOR 1
13 LG0-M9204-00X PLATE, BASE (B) 1
14 LG0-M9203-00X BLOCK, STOPPER (B) 1
15 LG0-M901X-00X STOPPER 1
16 LG0-M901Y-00X ARM 1
17 LG0-M9020-00X SHAFT, PIVOT 1
18 LG0-M9021-00X BUSH 1
19 LG0-M9022-00X BRACKET, CYL. (B) 1
20 LG9-M91A0-00X AIR CYLINDER 1
21 LG9-M90K6-00X SENSOR, CYL. ASSY. 1
22 LG0-M90AV-00X JOINT 1
23 LG0-M71AH-00X JOINT 2
24 LG0-M90AW-00X BUSH 1
25 LG0-M90AX-00X SPACER 1
26 99080-06600 CIRCLIP (E) 1
27 LG0-M90AN-00X JOINT 2
28 LG7-M91A1-00X RING, INSERT 2
29 LG0-M90AL-00X SOLENOID VALVE 1
30 LC0-M90K5-00X SV ASSY. 1
31 LG7-M900M-00X SUPPORT, BRG. 1
32 LE3-M901S-00X BRKT. SENSOR (R) 1
33 LE3-M900S-12X BRKT. SENSOR (L) 1
16
5. Conveyor Section
5-3. Edge Clamp
19
21
20
2
7
5
6
22
24
24
24
15
15
14
10
1
14
9
9
15
12
17
23
23
18
22
22
22
22
13
18
23
18
23
16
18
18
23
23
23
25
23
23
8
11
4
3
30
28
29
26
25
29
27
31
19
21
20
2
7
5
6
22
24
24
24
15
15
14
10
1
14
9
9
15
12
17
23
23
18
22
22
22
22
13
18
23
18
23
16
18
18
23
23
23
25
23
23
8
11
4
3
30
28
29
26
25
29
27
31
