5 2. Cover Section 2-2. Operation Panel 25 21 27 28 26 26 19 29 32 31 16 15 12 13 13 10 10 9 9 8 1 1 1 14 4 3 6 5 30 20 17 18 34 33 22 24 23 20 20 10 10 9 9 8 1 1 15 16 2 7 25 21 27 28 26 26 19 29 32 31 16 15 12 13 13 10…
4
2. Cover Section
2-1. Cover
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE3-M1301-10X FRAME, REAR 1
2 LE3-M1302-04X FRAME, LEFT 1
3 LE3-M1303-04X FRAME, RIGHT 1
4 LE3-M1315-02X RAIL, GUIDE L 1
5 LE3-M1316-02X RAIL, GUIDE R 1
6 LE3-M1317-01X BRKT, DAMPER 2
7 LE3-M1304-01X STAY, TOP L 1
8 LE3-M1305-01X STAY, TOP R 1
9 LE3-M1306-01X STAY, TOP C 2
10 LE3-M1308-00X COVER, TOP 1
11 K46-M1374-10X HINGE 2 2
12 LC4-M11A2-00X HINGE 2
13 LE3-M1311-01X STAY, HANDLE L 1
14 LE3-M1312-01X STAY, HANDLE R 1
15 LE3-M1313-01X STAY, HANDLE C 1
16 LE3-M1314-00X COVER, TOP F 1
17 LE3-M1309-01X PLATE, ACRYL 1
18 LE3-M1307-01X BRKT, SF KEY 1
19 LE3-M13H2-00X SAFETY KEY 1
20 LE3-M1324-01X PLATE, SPACER SF 1
21 LE3-M1310-03X PLATE, HANDLE 1
22 LE3-M1322-03X BLOCK, GUIDE 2
23 LE3-M131F-00X BRG. 2
24 LE3-M131G-00X PIN, BRG. 2
25 LE3-M131H-00X BRKT, SPONGE 2
26 LE3-M131P-00X SPONGE 2
27 LE3-M1339-00X SPACER, GOM 2
28 LE3-M1318-00X STOPPER, DOOR 2
29 LE3-M1334-00X ACRYL, CONV. L 1
30 LE3-M1335-02X COVER, CONV. R 1
31 LE3-M1336-01X ACRYL, CONV. R 1
32 LE3-M1330-10X BOLT, SHOULDER 4
33 LE3-M1331-10X SPACER, DAMPER 8
34 LE3-M1328-30X DAMPER 2
35 LG0-M9AA1-00X GOM 2
36 LC1-M13D2-00X LABEL, ALERT 1
37 LC1-M13D3-00X LABEL, ARERT 1
38 LE3-M13DD-20X PLATE, NAME 1
39 LE3-M13DA-12X LABEL, SERIAL 1
40 LE3-M13F4-00X RIVET 4
41
LC1-M13DD-A0X PLATE, NAME
1
42 LE3-M133A-00X COVER, CONV. LB 1
43 LE3-M133B-00X COVER, CONV. LU 1
5
2. Cover Section
2-2. Operation Panel
25
21
27
28
26
26
19
29
32
31
16
15
12
13
13
10
10
9
9
8
11
1
14
4
3
6
5
30
20
17
18
34
33
22
24
23
20
20
10
10
9
9
8
11
15
16
2
7
25
21
27
28
26
26
19
29
32
31
16
15
12
13
13
10
10
9
9
8
1
1
1
14
4
3
6
5
30
20
17
18
34
33
22
24
23
20
20
10
10
9
9
8
11
15
16
2
7
6
2. Cover Section
2-2. Operation Panel
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE3-M130A-00X CLAMP, MONITOR ASSY. 1
2 LE3-M130B-01X BASE, CLAMP-A 1
3 LE3-M130C-02X BASE, CLAMP-B 1
4 LE3-M130D-02X BASE, CLAMP-C 1
5 LE3-M130E-01X BAR, CLAMP 1
6 90134-06J070 BOLT, HEXAGON 1
7 LE3-M130G-01X LEVER, CLAMP 1
8 LE3-M130H-00X ROLLER, CLAMP 4
9 LE3-M130J-00X BRG. 8
10 LE3-M130K-00X WASHER, BELLEVILLE 8
11 LE3-M130L-00X SHAFT, ROLLER 4
12 LE3-M130M-00X PIN, HINGE 1
13 LE3-M130N-00X PLATE, MC 2
14 LE3-M130P-01X BAR, MONITOR 1
15 LE2-M1353-00X BRKT, BAR 2
16 LE3-M130S-01X PLATE, NUT 2
17 LE3-M130U-01X BASE, MONITOR 1
18 LE3-M130V-01X BASE, KEYBOARD 1
19 LE3-M13F1-00X SCREW, ALL 1
20 99711-16600 NUT, HEXAGON 5
21 LE3-M130X-01X COLLAR 1
22 LE3-M130Y-01X BRKT, KEY BOARD 1
23 LE3-M131T-00X CUSION, KB 1
24 LE3-M131U-00X TAPE, DOUBLE COATED 1
25 LE3-M131J-00X BRACKET, MONITOR 1
26 LE3-M131K-00X WASHER 2
27 LE3-M13F2-00X U-NUT 1
28 92907-16800 WASHER, BELLEVILLE 1
29 LE3-M130T-03X DUCT, MONITOR 1
30 LE3-M131L-00X CONNECTOR, DUCT 1
31 LE3-M131M-00X SADDLE, DUCT 1
32 LE3-M131N-00X BRKT, DUCT 1
33 LG0-M110P-01X PAD, MOUSE 1
34 LE3-M131A-00X GRIP, MONITOR 1
