2 CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS 2.15 ProFlow MAINTENANCE MANUAL MICRON 11/2017 71 2.15 PROFLOW 3 1 2 Fig.15: View on ProFlow Mount Item Description Item Description 1 Leadscrew 3 Drive Belt 2 Linear Bea…
2 CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
2.14 Squeegee Mechanism
70 MAINTENANCE MANUAL MICRON 11/2017
2.14 SQUEEGEE MECHANISM
1
2
3
4
5
Fig.14: View on Squeegee Mechanism
Item Description Item Description
1 Leadscrew (rear squeegee leadscrew
not shown)
4 Grease Nipples
2 Supernut (rear squeegee supernut not
shown)
5 Drive Belts
3 Spindle Shafts 6
2 CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
2.15 ProFlow
MAINTENANCE MANUAL MICRON 11/2017 71
2.15 PROFLOW
3
1
2
Fig.15: View on ProFlow Mount
Item Description Item Description
1 Leadscrew 3 Drive Belt
2 Linear Bearing Guide
2 CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
2.16 Rail System
72 MAINTENANCE MANUAL MICRON 11/2017
2.16 RAIL SYSTEM
1
2
3
4
Fig.16: View on Left Side Rail Assembly
Item Description Item Description
1 Horizontal Linear Bearing Guide (in 2
positions)
3 Clatter Bar (in 2 positions)
2 Ballscrew (in 2 positions) 4 Vertical Linear Bearing Guide (in 4 po-
sitions)
