00900067-02_OM_ProcessLens_EN
ASM ProcessLens Operation Manual Edition 06/2019 EN www.asm-smt.com
ASM ProcessLens
Operation Manual
Edition 06/2019 EN
www.asm-smt.com
All names identified by ® are registered trademarks of ASM Assembly Systems GmbH & Co. KG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
We have reviewed the contents of this publication to ensure consistency with the hardware and software described. Since variance
cannot be precluded entirely, we cannot guarantee full consistency. However, the information in this publication is reviewed regularly
and any necessary corrections are included in subsequent editions.
Copyright © ASM Assembly Systems Technical data subject to change
ASM Assembly Systems Singapore Pte Ltd
535 Yishun Industrial Park A
ASM Tech-Park Building 2
Singapore 768775
Item no.: 00900067-02
www.asm-smt.com Printed by ASM Assembly Systems
Operation - Introduction
3
www.asm-smt.com
1 Operation - Introduction
Introduction of ProcessExpert
ASM ProcessExpert is a self-learning inline expert system for electronics manufacturing. ASM ProcessExpert does not
only analyze processes, but also stabilizes, automatically optimizes and proactively controls them.
ASM ProcessEpert comprises of:
– A compatible DEK Printer.
– ASM ProcessLens (Single Lane or Dual Lane), Solder Paste Measurement (SPM) inline machine.
– ProcessEngine, intelligent software analyzing real time measurement results of ASM ProcessLens, taking control of
a DEK printer, stabilizing, optimizing and pro-actively keeping the printing process under control.
