Edison Printer

The most accurate printer in the market,

with advanced technology needed

for ne pitch applications.

Unmatched Accuracy and Speed

The Edison is the most accurate printer in the market.

Edison has built-in ±8 microns alignment, and ±15 microns

wet print repeatability (≥2 Cpk @ 6 sigma) proven through

CeTaq Print Capability Analysis (PCA) testing.

The Edison has a total throughput that is much faster than

current leading printers due in part to the highly-efficient

parallel processing of the stencil shuttle system, stencil

wiping, and vision alignment system.

This incredibly fast cycle time leaves room for extra steps

that improve the quality of critical electronics. Slower stencil

separation for optimal print definition, more frequent wiping

and a double print stroke after wiping all lead to improved

quality and yield.

Ultra-fine pitch and aperture printing

Component miniaturization, particularly in the smart device

market imposes technical challenges for printing equipment.

The MPM Edison meets these challenges with a 25% improve-

ment in wet print accuracy over current best-in-class printers.

Edison is optimized for ultra-fine pitch (0201M) printing with

a transfer efficiency up to 75% for small apertures. Single axis

closed-loop pressure control for the dual squeegee elimi-

nates front-to-back variation and maintains the set pressure

across the entire board surface.

Back To Back (BTB) Configurable

Ultra-fast, High Efficiency Wiping

A super-size 65m paper roll with patented constant

tension control, makes 10,000 prints possible before

a roll change is needed, reducing downtime and

operator interface. Wiping zone is isolated from

printing zone to avoid cross contamination.

Best Performance Closed-loop Squeegee

A single high precision load cell with closed-loop

pressure control and motor drive system enable

precise and consistent squeegee force control across

print stroke in both directions, which helps improve

yields especially for challenging thin substrate

printing in the semiconductor industry.

NEW Board Staging

The ability to have three boards in the machine

simultaneously. Pre-loading the board during the

print process results in reduced transfer times and

improved cycle time.

Fine pitch printing

Most Accurate

Fastest

Momentum II Printers

A proven, highly-productive printer

platform with a new set of enhanced

technologies.

Flexibility to meet growing demands

Momentum II is designed and built to be a no-nonsense

production machine. Cost-efficient and featuring a modest

footprint, it grows with the user; innovative patented fea-

tures can be added on or retrofitted as needed as the user’s

throughput demands grow.

Momentum’s alignment repeatability is ±11 microns

@ 6 sigma, Cpk ≥2. Wet print accuracy is ±17 microns

@ 6 sigma, Cpk ≥2. Tighter performance tolerances mean

higher repeatability with fewer defects.

The Momentum II series is designed with production needs

and the needs of the operator in mind. They’re champion

performers, meeting the demands of high throughput and

accuracy, yet at the same time are easy to learn, easy to use,

and offer user-friendly features including built-in wizards in

the Benchmark software program that provide direction for

all machine functions, utilities, and error recovery.

High Performance

Momentum® II New Features

 Newly designed cover set with larger window

and wider access inside the printer

 Solder paste roll height monitor for both upper

and lower limits and out of range alert

 Solder paste temperature monitor measures on

stencil and cartridge and has out of range alert

 Quick release squeegee for faster changeover

 Upgraded Benchmark GUI with new production

tools and easy to use Quickstart program

 Support pin placement and verification

with bottom-side image alignment

 New jar paste dispenser for increased productivity

 Adjustable stencil shelf

 EdgeLoc+ edge and top board clamping

NEW

Automated Support-Pin Placement

The Elite and HiE offers MPM’s patented tooling solu-

tion automatically places support pins in a software

programmable pattern simplifying both initial set-

up and product changeover. The newly developed

feature allows pin location to be easily identified and

verified with a bottom side image whether placing

pins automatically or manually.

Proven, Robust

Momentum® II Elite's Triple-Track

Processing Speed and Efficiency

The Momentum II Elite is the only MPM printer with

triple-track. All other MPM printers feature a single rail.

With triple track, cycle time is shortened because boards

don’t have to move single-file through the printer. A

new board can be indexed into the machine and posi-

tioned next to the center nest, readying to print, while

the two others are being loaded and offloaded. Instead

of one-board-at-a-time linear processing, cycle time can

be shaved by buffering PCBs inside the machine.

Features and Enhanced Technology

NEW Quick Release Squeegee

New quick release squeegee blades make changing

blades quick and easy

with no tools required.

It takes less than 30

seconds to change

the blade.

EnclosedFlow Printhead

EnclosedFlow ensures optimal aperture filling for fine

pitch devices and through-hole applications with crisp

uniform printing and less waste. Solder paste is held

within an enclosed chamber and is directly mechanically

pressurized during the print stroke.

RapidClean

RapidClean is a high-speed stencil solvent cleaning

innovation that slashes cycle time and improves stencil

cleaning performance, especially for fine-pitch. Rapid-

Clean reduces 3 wipe strokes to 2 and cuts cycle time by

5 – 6 seconds per print cycle over the standard wiper.

And because fewer

cleaning cycles are

required, RapidClean

can save up to $10K

USD per annum in

paper savings per

printer.

NEW

Automatic Paste Dispensing System

Dispense for standard cartridges or choose the new

jar dispenser. Paste is released in precise, measured

amounts across the

stencil in a clean, uni-

form bead. Deposition

volumes, frequency,

and placement are

user-programmable.

NEW Paste Height Monitor

The Paste Height Monitoring system is designed to

prevent defects caused by inadequate volumes of

paste on the stencil. It combines advanced software

and sensor technology to accurately monitor the paste

bead for volume consistency. Upper and lower limit

roll-height monitoring eliminates insufficient or excess

paste volumes. It’s a

non-contact solution

that can automatically

add more paste to the

stencil as it is needed.

NEW Paste Temperature Monitor

Patent-pending temperature monitoring ensures

proper paste viscosity to avoid bridging and voiding.

MPM paste temperature monitor allows paste to be

measured in the cartridge and/or on the stencil.

NEW Adjustable Stencil Shelf

Provides the flexibility to handle all stencil sizes with

a simple adjustment of the shelf. The robust design

provides better stability on all stencil sizes.

NEW EdgeLoc Board Clamping

The EdgeLoc system uses a side snugging technique that

removes the need for top clamps which interfere with the

PCB to stencil contact. The result is optimal gasketing and

more volumetrically consistent edge-to-edge prints. With

EdgeLoc II, robust flippers engage to secure the board

across the top edge ensuring board flatness then move out

of the way once the board is firmly gripped from the side.

EdgeLoc+ board

clamping is able to

change between

edge and top clamp-

ing simply through

software.

Camalot Inside™

Improve your production line’s flexibility and productiv-

ity with Camalot patented dispensing technology inside

the Momentum II

Elite and HiE. Includes

dual dispensing heads

mounted to the wiper

gantry.
