MODEL TCM-X300S 0306-001 Key No. P AR T No. P AR T NAME Q’ ty REMARKS NOTE 271 RL-2 15 1 630 1 19 8330 UNI T ,DR IV ER 1 APMD13(TR),APMD14(CHW), APMD19(BPC),#D3390 814RL-010-151 15 3 630 086 7473 UN IT ,DR IV ER 1 ASMD6(…
MODEL TCM-X300S
0306-001
270
ᯏ᪾ᑫࠅ㧝 MISCELLANEOUS PARTS-1
Fig. RL-2 XY ࡕ࠲࠼ࠗࡃ XY Motor Drivers
See Fig.L-1
Key No.9
158
194
195
196
157
194
195
196
190
194
195
196
193
155
154
153
192
191
199
198
197
190
156
199
198
197
199
198
197
199
198
197
151
159
159
190
189
160
MODEL TCM-X300S
0306-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
271
RL-2
151 630 119 8330 UNIT,DRIVER 1 APMD13(TR),APMD14(CHW),
APMD19(BPC),#D3390
814RL-010-151
153 630 086 7473 UNIT,DRIVER 1 ASMD6(X),SGDH-30AE-R
814RL-010-153
154 630 086 7480 UNIT,DRIVER 1 ASMD7(Y),SGDH-15AE-R
814RL-010-154
155 630 086 8630 UNIT,DRIVER 1 ASMD8(XYTR),SGDH-A5AE-R
814RL-010-155
156 630 119 8408 PLATE 1 814RL-010-156
157 630 115 3407 PLATE 1 814RL-010-157
158 630 115 4442 BRACKET 1 814RL-010-158
159 630 119 8323 UNIT,DRIVER 2 APMD16(LCVW),APMD22(L2CV),
APMD17(RCVW),APMD26((R2CV),
#D3380 814RL-010-159
160 630 048 3833 MECH PARTS(MOUNTING BASES 24 814RL-010-160
189 411 113 9109 SCR TRS 5X10 24 814RL-010-189
190 411 114 7807 SCR PAN+SW+W 4X10 6 814RL-010-190
191 411 113 2803 SCR PAN 5X8 4 814RL-010-191
192 411 008 2109 WASHER SPR 5 4 814RL-010-192
193 411 088 1702 WASHER V 5X10X1 4 814RL-010-193
194 630 000 7756 BOLT,HEX-SCT 17 814RL-010-194
195 411 141 6705 WASHER SPR 5 17 814RL-010-195
196 630 001 0220 WASHER 17 814RL-010-196
197 411 042 3001 SCR PAN 4X10 12 814RL-010-197
198 411 008 1706 WASHER SPR 4 12 814RL-010-198
199 411 119 2104 WASHER V 4X9X0.8 12 814RL-010-199
MODEL TCM-X300S
0306-001
272
ᯏ᪾ᑫࠅ㧝 MISCELLANEOUS PARTS-1
Fig. RL-3 ࡄࡢ࠻ࡦࠬ Transformer Power
297
298
299
251
See Fig.L-1
Key No.9
