Page
SAMSUNG TECHWIN
18
SM321
Conveyor Ass’y
Stock
NO. LEVEL PART NO. PART NAME Q'TY TYPE
28 ...3 J6602075A
TIMING BELT[92XL-025] 1 92XL-025 ○
29 ..2 J70531002A
DUMP-BOX 1 J70531002A ○
30 ..2 J6409011A
DUMP BOX[1/9 PAN] 1 1/9 PAN ○
31 ....4 J9053340A
PLACE STOPPER ASSY[J9053340A] 1 J9053340A
32 .....5 J7053684A
STOPPER TOP PLATE[J7053684A] 1 J7053684A ○
33 .....5 J6703007A
THROTTLE VALVE(ELBOW) 1 JNC4-M5 ○
34 ....4 J71531048B
PCB_GUIDE_END 2 J71531048A
35 ....4 J7053184A
SQUARE NUT M4 9 0131-641702 ○
36 ....4 J7053770A
IDLER SHAFT-M[J7053770A] 3 J7053770A ○
37 ....4 J7053763A
IDLER SPACER-M[J7053763A] 3 J7053763A ○
38 ...3 J6602074A
TIMING BELT[025-XL-396-AJ] 1 025-XL-396-AJ ○
○
39 ....4 J90531012A
STEP_MOTOR_ASSY 1 J90531012A
40 ....4 J6711077A
ELBOW FITTING 1 PL6-M5M
41 ...3 J6713034A
AIR TUBE(POLYYRETHANE)[U2-4-6*4(YELLOW)] 3.2 U2-4-6*4(YELLOW)
42 ...3 J6713017A
AIR TUBE (POLYURETHANE) 3.5 U2-4-6*4 (BLACK) ○
43 ...3 J6713016A
AIR TUBE (POLYURETHANE) 5.35 U2-4-4*2.5 (BLACK) ○
○
○
44 ...3 J6713035A
AIR TUBE(POLYYRETHANE)[U2-4-4*2.5(BLUE)] 2.5 U2-4-4*2.5(BLUE)
45 ...3 J90751018A
CONV_SENSOR_CABLE_ASSY J90751018A 1 J90751018A
46 ....4 J90831011A
CONV_FRONT_AC_MOTOR_CABLE_ASSY 1 SM21-MD041
47 ....4 J90831012A
CONV_REAR_AC_MOTOR_CABLE_ASSY 1 SM21-MD042
48 J90531052A CONV_ASSY_L460_W400_F_RL J90531052A
1
J90531052A
49 .....5 J6701018B
STOPPER CYLINDER 1 [WTS10*30-RS2] 1 WTS10*30-RS2 ○
50 .....5 J7053686A
STOPPER TOP PLATE-R[J7053686A] 1 J7053686A ○
51 ....4 J1300509
J9053344A
J6601008A
BALL BEARING [6000ZZ] 2 6000ZZ ○
52 .....5 J7053666A BEARING HOUSING SF[J7053666A]
1
J7053666A
53 .....5 J7053034A BEARING NUT-SF
1
0135-641077
P art L is t
Old No.
Reference
Page
SAMSUNG TECHWIN
19
SM321
Conveyor Ass’y
70 J90531055A CONV_ASSY_L610_W400_F_LR J90531055A
1
J90531055A
71
....4 J90531024A PLACE_STOPPER_ASSY
1
J90531024A
Stock
NO. LEVEL PART NO. PART NAME Q'TY TYPE
53 .....5 J6601123A BEARING[6804ZZ]
1
6804ZZ
○
○
○
54 ....4 J90531020A
PLACE_STOPPER-R_ASSY 1 J90531020A
55 .....5 J9080831A CONVEYOR WORK STEP MOTOR CABLE ASSY[SM_M
1
SM_MD034
56 .....5 J9080831A
CONVEYOR WORK STEP MOTOR CABLE ASSY[SM_M 1 SM_MD034
57 J90531053A CONV_ASSY_L460_W510_F_LR J90531053A
1
J90531053A
8 .....5 J6602080A TIMING BELT-STEP MOTOR[201-S3M-6]
1
201-S3M-6
○
9 .....5 J6602081A TIMING BELT-AC MOTOR[237-S3M-6]
1
237-S3M-6
○
39 ......6 J3104013A C/V STEP MOTOR [4S56Q-03076S]
1
4S56Q-03076S
○
58 ...3 J7153413A PULLEY-SPLINE[J7153413A]
3
J7153413A
○
○
59 ...3 J70531005B SPLINE_S_LARGE J70531005A
2
J70531005A
60 ...3 J9083109A CONVEYOR DIRECTION CHANGE CABLE ASSY[SM-
1
SM-CV030
61 ...3 J90611106A LONG_CONV_PCB_SENSOR_CABLE_ASSY SM-CV034
1
SM-CV034L
62 J90531054A
J90531001A
J90611038C
J90531002ACONV_ASSY_L460_W510_F_RL
1
J90531054A
31 ....4 J90531047A PLACE_STOPPER_ASSY J90531047A
1
J90531047A
63
64
.....5 J6711046A BOB ELBOW FITTING M-5ALU-4
2
M-5ALU-4
65
.....5 J6701080A AIR CYLINDER[MHY2-01-IU2054-D-M9N(3m)]
1
MHY2-01-IU2054-D-M9N(3M)
○
66
.....5 J7053745A PCB STOPPER[J7053745A]
1
J7053745A
....4 J70531095A PCB_GUIDE-FC J70531095A
1
J70531095A
67 J90531057A CONV_ASSY_L610_W460_F_LR J90531057A
1
J90531057A
68 ....4 J71531049B PCB_GUIDE_END_1
1
J71531049A
69 ....4 J71531050B PCB_GUIDE_END_2
1
J71531050A
P art L is t
Old No.
Reference
Large Type
LONG C/V
LONG C/V
LONG C/V
LONG C/V
LONG C/V
LONG C/V
LONG C/V
Page
SAMSUNG TECHWIN
20
SM321
Conveyor Ass’y
Reference
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock
72
...3 J66021002A FLAT_BELT_END_ZONE
4
MAM-5P-1570L
73 J90531067A CONV_ASSY_L660_W510_F_LR J90531067A 1 J90531067A
23 ....4 J70531096A PCB_GUIDE-RC J70531096A
1
J70531096A
P art L is t
