Page SAMSUNG TECHWIN 58 SM321 5 6 1 1 1 2 Y -B al l S cr ew Mo dul e As s’y ( 3/3 )
Page
SAMSUNG TECHWIN
57
SM321
6
6
9
Y-Ball Screw Module Ass’y (2/3)
Page
SAMSUNG TECHWIN
58
SM321
5
6
11
12
Y-Ball Screw Module Ass’y (3/3)
Page
SAMSUNG TECHWIN
59
SM321
Y-Ball Screw Module Ass’y
Reference
P art L is t
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock
1 J90541005A Y1-BALL_SCREW_MODULE
1
J90541005A
2 ....4 J6601124A SUPPORT UNIT[FK-15]
1
FK-15
○
3 ....4 J6606036A BALL SCREW[W2011P-3SS-C5T30]
1
W2011P-3SS-C5T30
○
4 ....4 J1300510 J6601020ABEARING [6002ZZ]
2
6002ZZ
○
5 ..2 J90611039A FRONT_FEEDER_UNLOCK_CABLE_ASSY SM-CV035
1
SM-CV035
6 ..2 J90611040A REAR_FEEDER_UNLOCK_CABLE_ASSY SM-CV036
1
SM-CV036
7 ..2 J6612036A COUPLING[SFC 050DA 12B-19B(TYPE A)]
2
SFC 050DA 12B-19B(TYPE A)
○
8 ..2 J3108064A SERVO MOTOR[MSMA102P1C01]
2
MSMA102P1C01
○
9 ...3 J66070077B LM_GUIDE[SSR25XW2UU+1480LHY-II] 1 SSR25XW2UU+1480LHY-II
10 J90541005A Y2-BALL_SCREW_MODULE
1
J90541005A
2 ....4 J6601124A SUPPORT UNIT[FK-15]
1
FK-15
○
3 ....4 J6606036A BALL SCREW[W2011P-3SS-C5T30]
1
W2011P-3SS-C5T30
○
4 ....4 J1300510 BEARING [6002ZZ]
2
6002ZZ
○
5 ..2 J90611039A FRONT_FEEDER_UNLOCK_CABLE_ASSY SM-CV035
1
SM-CV035
6 ..2 J90611040A REAR_FEEDER_UNLOCK_CABLE_ASSY SM-CV036
1
SM-CV036
7 ..2 J6612036A COUPLING[SFC 050DA 12B-19B(TYPE A)]
2
SFC 050DA 12B-19B(TYPE A)
○
8 ..2 J3108064A SERVO MOTOR[MSMA102P1C01]
2
MSMA102P1C01
○
9 ...3 J66070077B LM_GUIDE[SSR25XW2UU+1480LHY-II] 1 SSR25XW2UU+1480LHY-II
11 ...3 J7354024A CABLE CUSHION Y[J7354024A]
1
J7354024A
○
12 ...3 J7054256A CUSHION BRACKET Y[J7054256A]
1
J7054256A
○
