SM321 Technical Reference_Ver3 - 第62页
Page SAMSUNG TECHWIN 62 SM321 W in do w Ass ’y A A A 2 2 - A 2 - B 5 4 3 6
Page
SAMSUNG TECHWIN
61
SM321
ANC Ass’y
Reference
P art L is t
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock
1 J9056038A ANC ASSY[J9056038A]
1
J9056038A
2 ..2 J6703028A SPEED CONTROLLER [SS4-M5MA] 2 SS4-M5MA
3 ..2 J7156094A NOZZLE SHUTTER[J7156094A]
1
J7156094A
○
4 ..2 J9080778B ANC SENSOR CABLE ASSY[SM-CV010]
1
SM-CV010
○
No.1 at 87 page
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
Page
SAMSUNG TECHWIN
62
SM321
Window Ass’y
A
A
A
2
2-A
2-B
5
4
3
6
Page
SAMSUNG TECHWIN
63
SM321
Window Ass’y
Reference
P art L is t
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock
1 J9052289A WINDOW ASSY(SM320_STD)[J9052289A]
1
J9052289A
2 ..2 J9052291A WINDOW-FRONT ASSY(SM320_STD)[J9052291A]
2
J9052291A
○
2-A ...3 J6108007A HINGE[HINGE 65*32]
3
HINGE 65*32
○
2-B ...3 J6119051A HANDLE[AP-2 BLACK]
1
AP-2 BLACK
○
3 ...3 J67191010A GAS_SPRING KS2-300-P1-028
2
KS2-300-P1-028
○
4 ...3 J7252088A SPACER[J7252088A]
2
J7252088A
○
5 ...3 J6015601039
J6719050A
J7452036ASHOULDER_SCREW_MSB8-10
2
MSB8-10
○
6 ...3 J6042800003 WASHER_PWF8
2
PWF8
○
7 J9052290A WINDOW ASSY(SM320_ESD)[J9052290A]
1
J9052290A
8 ..2 J9052293B WINDOW-ESD ASSY(SM320_ESD)[J9052293B]
2
J9052293B
○
9 J90521024A WINDOW_ASSY-STD-R-SHORT J90521024A
1
J90521024A
10 ...3 J72520110C WINDOW-REAR J72520110C
1
J72520110C
11 ..2 J90521026A WINDOW_ASSY-R-SHORT J90521026A
1
J90521026A
12 J90521025A WINDOW_ASSY-ESD-R-SHORT J90521025A
1
J90521025A
13 ..2 J90521001A WINDOW_ASSY-R_TRAY_SAMSUNG
1
J90521001A
14
15
16
17
18
19
20
21
22
