3. Retrieval of Standard Component ID
To place components on a PCB, the IDs of the components to be placed
must be set up in the pattern program.
It is also required to check if the components to be placed are regis-
tered as standard component IDs through retrieval operation. Refer to
another instruction manual "Component Library Data (TIM-X Series)"
for details.
Retrieval of Standard Component IDs
(a) Before performing the retrieval operation,
the following information should be ob-
tained in advance from approval draw-
ings, a catalog, actual components, etc.
• Component Makers and Names
• Serial Nos. and Package Names Speci-
fied by Component Makers
(b) Refer to the instruction manual "Compo-
nent Library Data (TIM-X Series)" for how
to retrieve component IDs.
Registered Use the pertinent standard component IDs.
Not Registered Create new component library data.
Refer to "Section 4 Creation of New Compo-
nent Library" for details.
3. Retrieval of Standard Component ID
0107-001 1-3 Tg0502-PM-CL
4. Classification of Component Shapes
Component shapes are classified to distinguish each component library
data group.
4.1 Leadless Components
Table A3
Component Shapes Applicable Components for Reference
Cylindrical
Square
Deform Simple Shape
Complex Shape
4. Classification of Component Shapes
0107-001 1-4 Tg0502-PM-CL
• Cylindrical Components
Resistors, Capacitors, Diodes, and other
similar-shaped components
• Square Components
Resistors, Film Capacitors, Coils, Chip
Ceramic Filters, and other similar-shaped
components
• Deform Components
Tantalum Capacitors, Semi-Fixed
Variable Resistors, Aluminum Electro-
lytic Capacitors, Trimmer Capacitors,
and other similar-shaped components
• Special Components
(Components have three linear edges
or more)
Such as some battery and shielded
cases, etc.
Fig. A3
Fig. A4
Fig. A5
Fig. A6
4.2 Leaded Components
Table A4
Component Shapes Applicable Components for Reference
IC Simple Shape
(Components with Leads in
Simple Arrangement)
Complex Shape
(Components with Leads in
Complex Arrangement)
Connector Simple Shape
(Components with Leads in
Simple Arrangement)
Complex Shape
(Components with Leads in
Complex Arrangement)
4.2 Leaded Components
0107-001 1-5 Tg0502-PM-CL
• Leaded IC Packages
SOP, QFP, TSOP, PLCC, SOJ, LCC, and
other similar-shaped components
• Connectors
Connectors for FFC/FPC, PCB-to-PCB
Connectors, Wire-to-PCB
Connectors, PLCC Sockets, etc., and
other similar-shaped components
Fig. A7
Fig. A8
Fig. A9
Fig. A10
