1. Naming Standards of Component Library
• A component ID name consists of up to 32 characters.
• Component IDs are allocated to the provided standard component
library data based on the naming standards in "3. Naming Standards
of Standard Component Library".
• Before creating new component library data, refer to "2. Naming Stan-
dards of User Component Library" and allocate component IDs to
the data.
Note that a lot of component IDs will be required in the future.
It is advisable that a basic rule such as a rule described in "3. Naming
Standards of Standard Component Library" should be established and
component IDs should be determined based on the rule.
2. Naming Standards of User Component Library
Before creating a user component library, follow the criteria below to
determine component IDs.
Number of Characters : 1 to 32 characters
Alphanumerics : A to Z, a to z, and 0 to 9
Marks : Any marks on the keyboard can be used,
excluding the followings.
['] [:] [*] [,] [?]
(a) No blank can be set between characters.
(b) No blank can be set before and after a component ID (a string of
characters).
(c) No component ID can be specified, using only hyphens (-).
3. Naming Standards of Standard Component Library
The provided standard component library data is broadly classified into
two types - General Components (ICs excluded) and ICs.
Component IDs are determined based on the standards described on
the subsequent pages.
1. Naming Standards of Component Library
0107-001 3-1 Tg0502-PM-CL
3.1 General Components (ICs excluded)
3.1.1 Component Name, Component Size, Component Thick-
ness, Manufacturer's Model No. and No. of Leads
The characters from the first to the eighth show the component name,
component size, component thickness, manufacturer's model No. and
number of leads.
The first character should be an English letter (A to Z).
(1) Component Name (Abbreviation for Component Name)
Each component name is expressed using its specified compo-
nent abbreviation.
Example: "C1608T08---"
Capacitor of 1.6 × 0.8 mm in Size and 0.8 mm in Thick-
ness
3.1 General Components (ICs excluded)
0206-003 3-2 Tg0502-PM-CL
14
Component ID:
13121110987654321 15 16
3.1.1 Component Name, Component
Size, Component Thickness,
Manufacturer's Model No. and
No. of Leads
3.1.2 Serial No.
3.1.3 Abbreviated Name of
Component Makers
Fig. C1
3.1.4 Taping
Specifications
Corresponding Table for Component Name and Component
Abbreviation
Basic Form for Component ID (first 8 characters)
{{{{ ...... shows the component size.
T .......... shows the component thickness.
Table C1
Component Type Abbr. Part Name ID (First 8 Digits) Remarks
R R Resistor (Square) R{{{{T
R Resistor (Cylindrical) R{{{{M - -
RW Resistor W Chip RW{{{{ - -
RN Resistor Network RN{{{{X
: Number of Resistors
C C Capacitor (Square) C{{{{T
C Capacitor (Cylindrical) C{{{{M - -
ALC Aluminum Electrolytic Capacitor ALC{{{{ -
TAN Tantalum Capacitor TAN{{{{ : Case Name
L I Inductor I{{{{T
COIL Coil COIL{{{{
VL Variable Coil VL{{{{ - -
FL F Filter F{{{{T
AMF AM Filter AMF{{{{ -
FMF FM Filter FMF{{{{ -
LCF LC Filter LCF{{{{ -
DI DI Diode DI{{{{ -
DI Diode (Cylindrical) DI{{{{M -
TR TR Transistor TR{{{{ -
PTR Power Transistor PTR{{{{ -
CPTR Compact Power Transistor CPTR{{{{
MPTR Mini Power Transistor MPTR{{{{
HEMT Cross-Shaped Component HEMT{{{{
VR VR Semi-Fixed Variable Resistor VR{{{{ - -
LED LED LED LED{{{{ -
TC TC Trimmer Capacitor TC{{{{ - -
CN CN Connector CN{{PIN - {: # of Pins
SW SSW Slide Switch SSW{{{{ -
PSW Push Switch PSW{{{{ -
TSW Tact Switch TSW{{{{ -
CSA CSA Oscillator CSA{{{{ -
SMG Frequency Synthesizer SMG{{{{ -
ETC EMIS EMI Suppressor EMIS{{{{
LCT LC Trap LCT{{{{ -
SUG Surge Absorber SUG{{{{ -
THM Thermistor THM{{{{ -
CHE Check Terminal CHE{{{{ -
DIS Discriminator DIS{{{{ -
PHC Photocoupler PHC{{{{ -
HOL Hall Terminal HOL{{{{ -
PC Mini Probe Terminal PC{{{{ - -
IFT Chip IFT IFT{{{{ -
3.1 General Components (ICs excluded)
0111-002 3-3 Tg0502-PM-CL
