4OM-1610 2-13 3. Machine Information : Chap.2 Management Information Code Display Area A (The outline of the Management Information) Display Area B (The details of the Management Information) 030442 Operation Requirement…
4OM-1610
2-12
3. Machine Information : Chap.2
0911-001
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
018902 Feeder communication
Feeder(Front) is on communication. Please wait for it, and then operate again.
018a01 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.(Rear)
018a02 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.(Front)
018b01 Library Tape Width check
Library Tape Width differs from Feeder. Please check Library and Feeder.(Rear)
018b02 Library Tape Width check
Library Tape Width differs from Feeder. Please check Library and Feeder.(Front)
019001 Support Pin
Please move exchange position of support pin.
019002 Support Pin
Noz for enchasing support pin is not set, or Odd-shape noz is set.
019003 Support Pin
Placement data in current differs from it of Support Pin of current pattern program.
Please set-up the support pin.
030162 Operation Requirement
The pattern cannot be switched
030416 Operation Requirement
ACV server does not pass the authorization. Please retry connection to server on
a screen [UNIT ADJ]-[ACV Set].
03041C Operation Requirement
ACV Check Error. Component ID on the feeder is not same as one specied by
current program.
030430 Operation Requirement
Can not detect Feeder cart(Rear). Please set Feeder cart to the inside.[B0910,
B0911]
030420 Operation Requirement
Communications with the ACV server is impossible. After conrming the ACV
server, please try to perform it again in the tab sheet: [MAINT]-[UNIT ADJ]-[ACV
ADJ].
030431 Operation Requirement
Can not detect Feeder cart(Front). Please set Feeder cart to the inside.[B0910,
B0911]
030432 Operation Requirement
The connector of the feeder base (rear) is not connected to the main body, so
please connect it. [B0916]
030433 Operation Requirement
The connector of the feeder base (front) is not connected to the main body, so
please connect it. [B0916]
030440 The Safety cover is open. Please close it. (Caution : Stage Ready cannot be ON
by manual operation because of no Cart)
030441 Operation Requirement
It is impossible to do pass operation without Cart because func of Traceability is
valid. Please restart after setting Option invalid.
4OM-1610
2-13
3. Machine Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
030442 Operation Requirement
It cannot move because a simple Cover locked. First, set Stage ready OFF, then
set Stage ready ON.
030501 Misidentication a type of multi-tray
The connected Tray unit(Rear) doesn't match setup of Device. Please conrm a
type of tray unit, set it on unit exchange screen later.
030502 Misidentication a type of multi-tray
The connected Tray unit(Front) doesn't match setup of Device. Please conrm a
type of tray unit, set it on Unit Exchange Screen later.
030601 Conrmation of the position of Noz Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
set the location of Noz stocker of Device(Rear) on Unit exchange Screen.
030602 Conrmation of the position of Noz Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
set the location of Noz stocker of Device(Front) on Unit exchange Screen.
030603 Conrmation of the position of Noz Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
conrm the location of Noz stocker of Device(Rear).
030604 Conrmation of the position of Noz Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
conrm the location of Noz stocker of Device(Front).
050201 Conrmation of P.C.B. existence
Remove P.C.B. from Conveyor
050202 Conrmation of P.C.B. existence
P.C.B. is detected from Input position because Finish mode is set [Output]. Please
P.C.B. from conveyor.
050203 Conrmation of P.C.B. existence
P.C.B. is detected from Output position because Finish mode is set [Input]. Please
P.C.B. from conveyor.
050204 Conrmation of P.C.B. existence
P.C.B. was detected from Inlet sensor of input conveyor. Please remove P.C.B.
050205 Conrmation of P.C.B. existence
The operation mode of Lane A is set [STOP]. Please remove P.C.B. when not
transferred.
050206 Conrmation of P.C.B. existence
The operation mode of Lane B is set [STOP]. Please remove P.C.B. when not
transferred.
050301 Conrmation of Firmware version
Firmware of transfer driver is not the latest version. Please update it with the latest
version.
050401 Manual transfer
P.C.B. (X>260mm) which is set by PP data is unable to take Input Position.
050402 Manual transfer
Please operate after removing P.C.B. from output conveyor. There is a possibility
of pushing and rising with Stopper.
0911-001
4OM-1610
2-14
3. Machine Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
050403 Manual transfer
It is impossible to take from Sensor Detection of Input Position. Please put P.C.B.
on Input Conveyor, or move it to Output position in Recovery Menu.
050501 Convert Width Setup
Please set conveyor width 49.5 to 461.5mm. The total of P.C.B. size/offset/
clearance is over movable range.
050502 Convert Width Setup
Please set conveyor width 49.5 to 382.5mm. The total of P.C.B. size/offset/
clearance is over movable range.
050503 Convert Width Setup
Movable Range for the destination of W1 is set. Please check P.C.B. size/offset/
clearance of Lane A.
050504 Convert Width Setup
Movable Range for the destination of W1 is set. Please check P.C.B. size/offset/
clearance of Lane A.
050505 Convert Width Setup
Movable Range for the destination of W2 is set. Please check P.C.B. size/offset/
clearance of Lane A
050506 Convert Width Setup
Movable Range for the destination of W2 is set. Please check P.C.B. size/offset/
clearance of Lane A.
050507 Convert Width Setup
Movable Range for the destination of W3 is set. Please check P.C.B. size/offset/
clearance of Lane B.
050508 Convert Width Setup
Movable Range for the destination of W3 is set. Please check P.C.B. size/offset/
clearance of Lane B.
050509 Convert Width Setup
These is a possibility of the interference with W1 and W2. Please check P.C.B.
size/offset/clearance of Lane A.
05050a Convert Width Setup
There is a possibility of the interference with W2 and W3. Please Check P.C.B.
size/offset/clearance of Lane A/B.
050601 Middle Conveyor
Rotation Direction set of Middle Conveyor in supply side differs from Main Device
transfer direction. Please change the rotation direction of Middle conveyor.
050602 Middle Conveyor
Emergency Stop switch of middle conveyor in supply side is pressed. Please
cancel it.
050603 Middle Conveyor
Safety Cover of middle conveyor in supply side is open. Please close it.
050604 Middle Conveyor
Input Machine communication mode is set [PUSHER]. Cannot use [PUSHER]
mode when Middle Conveyor is contacted.
0911-001
