4OM-1610
3-46
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
424201 Detection of output conveyor P.C.B.
P.C.B. was detected before starting output for output machine
Remove P.C.B. from Conveyor.
424202 Detection of output conveyor P.C.B.
The output for Output machine is completed, but P.C.B. on conveyor was detected
Remove P.C.B. from Conveyor.
424301 Detection of positioning conveyor(R) P.C.B.
No P.C.B. on conveyor
Output P.C.B. is not detected.
Please conrm whether P.C.B. is detected correctly or not.
424302 Detection of positioning conveyor(R) P.C.B.
The placement was completed, but P.C.B. was not detected.
Placed P.C.B. is not detected.
Please conrm whether P.C.B. is detected correctly or not.
425101 Detection of Input conveyor sensor
Decrease sensor was detected before starting
Remove P.C.B. from Input Conveyor.
425102 Detection of Input conveyor sensor
Decrease sensor was not detected before starting
Placing P.C.B. is not found internal machine.
1. Please put P.C.B. on the sensor
2. Because there is a possibility of P.C.B. falling, please conrm the width of
conveyor.
425103 Detection of Input conveyor sensor
Stop sensor was detected before starting
Remove P.C.B. from Input Conveyor.
425104 Detection of Input conveyor sensor
Stop sensor was Not detected before starting
Placing P.C.B. is not found internal machine.
1. Please put P.C.B. on the sensor
2. Because there is a possibility of P.C.B. falling, please conrm the width of
conveyor.
425105 Detection of Input conveyor sensor
P.C.B. on decrease sensor was detected after movement completion
Remove P.C.B. from Input Conveyor.
425106 Detection of Input conveyor sensor
P.C.B. on decrease sensor was not detected after movement completion
Please check whether P.C.B. is detected correctly.
Conrm whether the sensor doesn’t have Error.
425107 Detection of Input conveyor sensor
P.C.B. on stop sensor was detected after movement completion
Remove P.C.B. from Input Conveyor.
425108 Detection of Input conveyor sensor
P.C.B. on stop sensor was not detected after movement completion
Please check whether P.C.B. is detected correctly.
Check whether the sensor doesn’t have Error.
4OM-1610
3-47
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
425109 Detection of Input conveyor sensor
P.C.B. on Input conveyor was detected
Remove P.C.B. from Conveyor.
42510a Detection of Input conveyor sensor
P.C.B. on Input conveyor was not detected
Please check whether P.C.B. is detected correctly.
Check whether the sensor doesn’t have Error.
42510b Detection of Input conveyor sensor
2 P.C.B. pieces on conveyor exist.
Remove it if unnecessary P.C.B. exists, when checking P.C.B. on Conveyor.
42510c Detection of Input conveyor sensor
P.C.B. on sensor was detected in the state of not placing P.C.B.
There is a possibility whether P.C.B. is inserted or P.C.B. arrived before detecting
signals.
42510d Detection of Input conveyor sensor
Disengaged P.C.B. of Input conveyor
Possible to driver continuously. Please conrm the state of P.C.B. if it is not
removed purposely
42510e Detection of Input conveyor sensor
P.C.B. was not detected when placement was completed
P.C.B. from Input Machine is not received and sent.
Please conrm whether P.C.B. on Input conveyor is caught.
42510f Detection of Input conveyor sensor
P.C.B. was detected from Input conveyor sensor
P.C.B. is inserted though the mode that could not be inserted.
Please remove the inserted P.C.B..
425110 Detection of Input conveyor sensor
P.C.B. was detected from Input conveyor sensor
P.C.B. is inserted in P-OUT valid mode.
425201 Input conveyor timeout
Placement was not completed within predetermined time.
There is a possibility that P.C.B. is caught, or dropped from Conveyor.
Please check the transition with Input Machine.
425202 Input conveyor timeout
Output was not completed within predetermined time.
There is a possibility that P.C.B. is caught, or dropped from Conveyor.
Please check the above conveyor.
425301 Input conveyor Error
Error in Input conveyor
-----
426101 Detection of positioning conveyor sensor
Decrease sensor of input position was detected before starting.
There is an indenite P.C.B. on Input position decelerating sensor.
Please remove P.C.B..
4OM-1610
3-48
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
426102 Detection of positioning conveyor sensor
Decrease sensor of input position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
426103 Detection of positioning conveyor sensor
Stop sensor of input position was detected before starting.
There is an indenite P.C.B. on Input position stop sensor.
Please remove P.C.B..
426104 Detection of positioning conveyor sensor
Stop sensor of input position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
426105 Detection of positioning conveyor sensor
Decrease sensor of input position was detected after starting.
There is an indenite P.C.B. on Input position decelerating sensor. Please remove
P.C.B..
426106 Detection of positioning conveyor sensor
Decrease sensor of input position was not detected after starting.
Please check whether P.C.B. is detected correctly.
Check whether the sensor doesn’t have Error.
426107 Detection of positioning conveyor sensor
Stop sensor of input position was detected before starting.
There is an indenite P.C.B. on Input position stop sensor.
Please remove P.C.B..
426108 Detection of positioning conveyor sensor
Stop sensor of input position was not detected before starting.
Please check whether P.C.B. is detected correctly.
Check whether the sensor doesn’t have Error.
426109 Detection of positioning conveyor sensor
Decrease sensor of output position was detected before starting.
There is an indenite P.C.B. on Output position decelerating sensor.
Please remove P.C.B..
42610a Detection of positioning conveyor sensor
Decrease sensor of output position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
42610b Detection of positioning conveyor sensor
Stop sensor of output position was detected before starting.
There is an indenite P.C.B. on Output position stop sensor.
Please remove P.C.B..
