4OM-1610
3-67
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
49621b Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621c Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621d Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621e Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621f Conveyor Width W2 Error
System Error in Conveyor Width W2.
System Error of internal driver.
Driver error is supposed if this problem happens frequently.
496220 Conveyor Width W2 Error
Communication Error in Conveyor Width W2.
1. Conrm connection to communication cable.
2. Conrm Power supply(24V).
3. Conrm the communication setting of PCI board.
4. Conrm the address of driver and communication rate setting.
496801 Transit communication Error
Communication error occurred in the transfer section.
1. Conrm connection to communication cable.
2. Conrm Power supply(24V).
3. Conrm the communication setting of PCI board.
4. Conrm the address of driver and communication rate setting.
496802 Conveyor Width W1-axis communication Error
Communication error occurred in the W1-axis transfer driver.
1. Conrm connection to communication cable.
2. Conrm Power supply(24V).
3. Conrm the communication setting of PCI board.
4. Conrm the address of driver and communication rate setting.
496803 Conveyor Width W2-axis communication Error
Communication error occurred in the W2-axis transfer driver.
1. Conrm connection to communication cable.
2. Conrm Power supply(24V).
3. Conrm the communication setting of PCI board.
4. Conrm the address of driver and communication rate setting.
496901 Conveyor Width-axis Time-out
Time-out of Zeroing
Check out the dirt, error, disconnection of sensor.
If there is no problem with sensor, the problem could be with motor wire/single
error.
0911-001
4OM-1610
3-68
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
496902 Conveyor Width-axis Time-out
Time-out
Check out the dirt, error, disconnection of sensor.
If there is no problem with sensor, the problem could be with motor wire/single
error.
497001 On manual operation Alarm
Zeroing Error
LS, discontinuous zeroing movement, was detected.
Check out the dirt, error of sensor and error in Motor body etc.
497002 On manual operation Alarm
Out-of-Control was detected.
Motor Out-of-Control which is over the width of Out-of-Control detecting occurred.
Please execute all zeroing again, and the restart production.
Please set motor speed slow if it happens frequently. Also, in a case of structure
motor Error.
497003 On manual operation Alarm
Error in Motor Power voltage
Motor power voltage dropped.
Check out the Power supply line(48V Line)
497004 On manual operation Alarm
STP input was detected.
STP input is detected. The function to stop motor by Hard signal.
497005 On manual operation Alarm
Over-current
Error in Motor output line.
Check out the motor wiring,
497006 On manual operation Alarm
Limit Sensor(+) was detected.
+LS signal was detected for moving for (+).
Please check the dirt of +LS sensor, disconnection.
497007 On manual operation Alarm
Limit Sensor(-) was detected.
-LS signal was detected for moving for (-).
Please check the dirt of -LS sensor, disconnection.
497008 On manual operation Alarm
Motor disconnection was detected
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
497009 On manual operation Alarm
Error in Control Power Voltage
Control power for driver dropped.
Check out the Power supply line.(24V Line)
49700a On manual operation Alarm
-----
Reserved Function of driver. Please make inquiries when error is detected.
0911-001
4OM-1610
3-69
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
49700b On manual operation Alarm
-----
Reserved Function of driver. Please make inquiries when error is detected.
49700c On manual operation Alarm
-----
Reserved Function of driver. Please make inquiries when error is detected.
49700d On manual operation Alarm
-----
Reserved Function of driver. Please make inquiries when error is detected.
49700e On manual operation Alarm
-----
Reserved Function of driver. Please make inquiries when error is detected.
49700f On manual operation Alarm
System Error
System Error of internal driver.
Driver error is supposed if this problem happens frequently.
497101 Before setup P.C.B. detected
PCB was detected on Input conveyor.
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please conrm that P.C.B. is existing in Machine.
497102 Before setup P.C.B. detected
PCB was detected on Positioning Conveyor(Input position)
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please conrm that P.C.B. is existing in Machine.
497103 Before setup P.C.B. detected
PCB was detected on Positioning Conveyor(Output position)
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please conrm that P.C.B. is existing in Machine.
497104 Before setup P.C.B. detected
PCB was detected on Output conveyor.
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please conrm that P.C.B. is existing in Machine.
497105 Before setup P.C.B. detected
PCB was detected on Input conveyor of A Lane.
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please conrm that P.C.B. is existing in Machine.
497106 Before setup P.C.B. detected
PCB was detected on Positioning Conveyor of A lane(Input position)
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please conrm that P.C.B. is existing in Machine.
