4OM-1610
3-73
3. Error IDs and Remedial Procedures : Chap.3
3.8 Others
Error ID Error Name, Description, Cause, and Remedy
4b0201 Feeder communication Error.
Communication with the feeder has an error.
Please check the number of component remain.
4b0204 Feeder communication Error.
Communication with feeder was not completed within predetermined time.
(Please take out and insert feeder.)
-----
4b0205 Feeder communication Error.
Failed in processing information read, Please put the Cart down, or pull out and
insert Feeder.
-----
4b0206 Feeder communication Error.
Failed in Program-changed. Please put the Cart down, or pull out and insert
Feeder.
-----
4b0207 Feeder communication Error.
Failed in Splicing survey setup. Please put the Cart down, or pull out and insert
Feeder.
-----
4b0208 Feeder communication Error.
Cannot send it because of Error of Serial Communication process. Please put the
Cart down, or pull out and insert Feeder.
-----
4b0302 Feeder Base
The feeder unclamp operation was not completed within predetermined time.
-----
4b0304 Feeder Base
The feeder clamp operation was not completed within predetermined time.
-----
4b0305 Feeder Base
The feeder base ascent operation was not completed within predetermined time.
Check the feeder base upper limit position.
4b0306 Feeder Base
The feeder base descent operation was not completed within predetermined time.
Check the feeder base lower limit position.
4b0307 Feeder Base
The connector (Rear side) for the feeder base worked off. Do not remove the
connector during feeder base ascent.[B0916]
Connect the connector (rear) for the feeder base to the machine main body.
4b0308 Feeder Base
The connector (Front side) for the feeder base worked off. Do not remove the
connector during feeder base ascent.[B0916]
Connect the connector (front) for the feeder base to the machine main body.
0911-001
4OM-1610
3-74
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
4b0310 Feeder Base
The power was not turned on, or emergency stop was detected.
Please turn on the machine after conrm that Emergency Stop button is not
pressed.
4b0311 Feeder Base
Feeder Cart could not be detected.
Please execute operation again after setting Feeder Cart in predetermined place.
Please conrm whether it set in if the set is already done well.
4b0312 Feeder Base
Connector of Feeder Cart is not connected
Please execute operation again after connecting connector of Feeder Cutter.
4b0313 Feeder Base
NL-axis interlock was detected
Please execute zeroing when NL-axis is fallen.
4b0314 Feeder Base
Error in Feeder Base movement
-----
4b0315 Feeder Base
Time-out in Clamp Movement of Elevator Unit
-----
4b0316 Feeder Base
Time-out in Unclamp Movement of Elevator Unit
-----
4b0317 Feeder Base
Illegal current position of Feeder base (Rear)
Please conrm Feeder base, and the sensor of Cylinder Upper limit
detection[B0614], Cylinder Lower limit detection[B0615].
4b0318 Feeder Base
Illegal current position of Feeder base (Front)
Please conrm Feeder base, and the sensor of Cylinder Upper limit
detection[B0614], Cylinder Lower limit detection[B0615].
4b0319 Feeder Base
Positioning dropping prevention stopper(Rear) cannot cancel lock.
Please conrm the state of Feeder base and detect sensor of positioning drop
prevention lock[B0912][B0913]
4b031A Feeder Base
Positioning dropping prevention stopper(Front) cannot cancel lock.
Please conrm the state of Feeder base and detect sensor of positioning drop
prevention lock[B0912][B0913]
4b031B Feeder Base
Positioning dropping prevention stopper(Rear) cannot lock.
Please conrm the state of Feeder base and detect sensor of positioning drop
prevention lock[B0912][B0913]
4b031C Feeder Base
Positioning dropping prevention stopper(Front) cannot lock.
Please conrm the state of Feeder base and detect sensor of positioning drop
prevention lock[B0912][B0913]
4OM-1610
3-75
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
4b0501 Manual alignment Error
Operation was not completed within predetermined time.
-----
4b050f Manual alignment Error
Error was detected during operation.
-----
4b0701 Connection Error.
Failed in communications with the Control CPU.
-----
4b0702 Connection Error.
Failed in communications with the Recog. CPU.
-----
4b0801 Linear measure operation is abnormal.
Linear measure was found abnormality while measuring.
There is a possibility of Light Emitter and Receiver broken.
Please conrm Error from Log Request Screen(Unit adjustment → Linear
measure Sensor Screen)
4b0802 Linear measure operation error
The measurement by the linear measure sensor was not completed on time.
Communication connector of Linear measure Sensor P.C.B is taken off.
Please conrm whether the items of LS-RLS-S(Device Check → List) is Y
ellow.
HLS communication cable could not be connected and such like things.
4b0803 Linear measure operation error
There is a problem in the values measured by the linear measure sensor.
Light Emitter and Receiver could have aw and soil. Please clean it up.
Please press [Operation] on the screen(Unit adjustment → Linear measure
Sensor → Detection test Screen) and conrm whether there is an error
4b0804 Linear measure operation error
There is a problem in the values measured by the linear measure sensor.
There is a possibility of Line Sensor P.C.B. broken
4b0805 Linear measure operation error
There is a problem in the values measured by the linear measure sensor.
A small light quantity of Light Emitter. Please exchange Light Emitter.
4b0806 Linear measure operation error
There is a problem in the values measured by the linear measure sensor.
There is a possibility of Line Sensor P.C.B. broken.
Either
, Please update Version on the screen(Unit adjustment → Linear measure
Sensor → Correct data read Screen)
4b0807 Linear measure operation error
There is a problem in the values measured by the linear measure sensor.
Please conrm Error from Log Request Screen(Unit adjustment → Linear
measure Sensor Screen). Either, please conrm whether the items of LS-RLS-
S(Device Check -> List) is Yellow. HLS communication cable could not be
connected and such like things.
