4OM-1610
3-118
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
60470f Teaching Height of Traverse Chute
Flange of Nozzle is not detected within the predetermine range.(Under 0.2mm)
-----
604710 Teaching Height of Traverse Chute
Flange of Nozzle is not detected within the predetermine range.(Over 2.5mm)
-----
604711 Teaching Height of Traverse Chute
The height of Flange of Nozzle is not changed.(Nozzle pressed is not detected.)
-----
604712 Teaching Height of Traverse Chute
Program Error
-----
604713 Teaching Height of Traverse Chute
Offset is 1mm less than the set value.
-----
604714 Teaching Height of Traverse Chute
Offset is 1mm more than the set value.
-----
604715 Teaching Height of Traverse Chute
The value of Flowmeter is higher than 5.0V.
-----
604716 Teaching Height of Traverse Chute
The value of Flowmeter is lower than 4.7V.
-----
604717 Teaching Height of Traverse Chute
There is no measured data of Noz 1. It is necessary to measure Noz1
　
rst.
-----
604718 Teaching Height of Traverse Chute
Cannot measure it for XY-coord is not dened.
-----
604719 Teaching Height of Traverse Chute
Error in Flowing Quantity
----
T4C13
0911-001
4OM-1610
3-119
3. Error IDs and Remedial Procedures : Chap.3
0911-001
3.12 System error
Error ID Error Name, Description, Cause, and Remedy
FE0101 Auto Control Error
In auto control the operation can't be continued Error(Refer to syslog)
-----
FE0201 XY Control Error
Error in XY Control Sequence (cf. Syslog)
-----
FE0202 XY Control Error
Error in interface check of XY Control Sequence (cf. Syslog)
-----
FE0203 XY Control Error
Timeout in XY Control
-----
T4C15
