General Contents
Chapter 5 Lubrication points and schedule
1. Lubrication tools and grease 5-1
1.1 Compatible grease 5-1
1.2 Grease gun 5-1
2. Lubrication points 5-2
2.1 Printing head unit 5-2
2.1.1 SY-axis 5-2
2.1.2 SZ-axis 5-3
2.2 Conveyor unit 5-4
2.2.1 W1-axis, W2-axis, W3-axis (conveyor auto width) 5-4
2.3 Table unit 5-5
2.3.1 X1-axis and X2-axis 5-5
2.3.2 Y-axis 5-6
2.3.3 Z-axis 5-7
2.3.4 PU-axis 5-8
2.4 Recognition unit 5-9
2.4.1 CX-axis 5-9
2.4.2 CY1-axis and CY2-axis 5-10
2.5 Other lubrication points 5-11
2.5.1 Cleaning unit 5-11
2.5.2 Suction unit 5-12
Appendix
1. Specification A-1
1.1 Air regulator unit A-1
1.1.1 Supply air pressure A-1
1.2 Power connection terminals A-2
1.3 Connection between machines A-3
1.3.1 PREVIOUS INTERFACE connector A-4
1.3.2 NEXT INTERFACE connector A-5
1.4 Adapted mask A-6
1.4.1 Themaskamesizeandthemaskstandardposition A-6
1.5 Inverter A-7
2. Periodic inspection check sheet A-9
3. User support A-12
3.1 YAMAHA Service website A-12
4. YSP10 Maintenance parts A-13
The instruction manual of this machine is written for those who operate
this machine.
Please read this manual carefully for correct operations and pay special
attention to safety precautions.
After reading through this manual, please use this manual as an
occasional reference and keep it within reach.
Introduction
Contents
1. About this manual i
2. Contents of each chapter ii
3. Maintenance list iii
1. About this manual
i
Introduction
1. About this manual
The instruction manual of this machine is written for those who operate this machine. Please read this
manual carefully for correct operations and pay special attention to safety precautions.
After reading through this manual, please use this manual as an occasional reference and keep it within
reach.
►
Parts descriptions
The maintenance part (part Nos.) given in this manual are the original part Nos. which were assigned to
the parts when this manual was issued. Because these part Nos. may be changed without prior notice, be
sure to verify the latest part Nos. before ordering parts.
Moreover, this document is not a periodical publication. See YAMAHA Service Website for the latest
informations.
n
NOTE
See Appendix "3. User support" for YAMAHA Service Website.
