USC00017/10.2021 | Electric Drive s and Controls Go T o Bosch Re xroth Corporation 11 IndraDrive C - Pow er Section Go T o Focuse d Del ive r y Progr am: Dr ive Syste ms IndraDrive C - P ow er Section Indr aD ri ve set s…
10 Bosch Rexroth Corporation Electric Drives and Controls GoTo | USC00017/10.2021
R911327329 HCS01.1E-W0018-A-03-B-ET-EC-EC-NN-NN-FW 3 5 day(s)
R911338289 HCS01.1E-W0018-A-03-B-ET-EC-NN-L3-NN-FW 3 5 day(s)
R911331608 HCS01.1E-W0018-A-03-B-ET-EC-NN-L4-NN-FW 5 5 day(s)
R911325247 HCS01.1E-W0018-A-03-B-ET-EC-NN-NN-NN-FW 5 5 day(s)
R911337330 HCS01.1E-W0018-A-03-E-S3-EC-NN-L3-NN-FW 3 5 day(s)
R911328446 HCS01.1E-W0018-A-03-E-S3-EC-NN-NN-NN-FW 3 5 day(s)
R911335595 HCS01.1E-W0028-A-03-B-ET-EC-NN-L3-NN-FW 3 5 day(s)
R911331611 HCS01.1E-W0028-A-03-B-ET-EC-NN-L4-NN-FW 5 5 day(s)
R911325248 HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW 5 5 day(s)
R911340084 HCS01.1E-W0028-A-03-B-ET-EC-NN-S4-NN-FW 3 5 day(s)
R911340386 HCS01.1E-W0028-A-03-E-S3-EC-NN-L3-NN-FW 3 5 day(s)
R911328447 HCS01.1E-W0028-A-03-E-S3-EC-NN-NN-NN-FW 3 5 day(s)
R911336673 HCS01.1E-W0054-A-03-B-ET-EC-NN-L3-NN-FW 3 5 day(s)
R911332723 HCS01.1E-W0054-A-03-B-ET-EC-NN-L4-NN-FW 5 5 day(s)
R911331185 HCS01.1E-W0054-A-03-B-ET-EC-NN-NN-NN-FW 5 5 day(s)
R911336255 PFM04.1-512-NW 5 5 day(s)
USC00017/10.2021 | Electric Drives and Controls GoTo Bosch Rexroth Corporation 11
IndraDrive C - Power Section
GoTo Focused Delivery Program: Drive Systems
IndraDrive C - Power Section
IndraDrive sets new standards in drive technology with a combination
of three product advantages: scalability in power and functionality,
consistency in technology, engineering and operation and openness in
communication. The IndraDrive C series of converters integrate inverter
and power supply in one unit. The compact construction contains additional
mains connection components, making it particularly suitable for single and
multi axis applications.
For complete engineering and design information: GoTo www.boschrexroth-us.com/GoToDrivesystems
Features
• Ethernet-based communications, multi-protocol support: SERCOS III, Pro Net IO, EtherNet/IP and EtherCat
• Compact converters and modular inverters on one platform
• Integrated motion logic with IEC-compliant PLC
• Drive-integrated safety technology
• Energy efcient product - DC bus sharing
• Standard , Servo and Synchronization modes available
• Complete range of scalable drives
• Digital inputs/outputs and analog input on board
• Intelligent operating panel with programming function supports device swap without a PC
• Integrated brake resistor, alternative an external brake resistor can be connected
12 Bosch Rexroth Corporation Electric Drives and Controls GoTo | USC00017/10.2021
Part Number Description Max. Quantity Shipment (Business Days)
R911298371 HCS02.1E-W0012-A-03-NNNN 3 5 day(s)
R911298374 HCS02.1E-W0028-A-03-NNNN 3 5 day(s)
R911298373 HCS02.1E-W0054-A-03-NNNN 3 5 day(s)
R911298372 HCS02.1E-W0070-A-03-NNNN 3 5 day(s)
R911308417 HCS03.1E-W0070-A-05-NNBV 3 5 day(s)
R911308419 HCS03.1E-W0100-A-05-NNBV 3 5 day(s)
R911308421 HCS03.1E-W0150-A-05-NNBV 3 5 day(s)
R911308415 HCS03.1E-W0210-A-05-NNBV 3 5 day(s)
R911344906 HCS03.1E-W0070-A-05-NNBN 1 5 day(s)
R911344910 HCS03.1E-W0100-A-05-NNBN 1 5 day(s)
R911344922 HCS03.1E-W0150-A-05-NNBN 1 5 day(s)
