Choke
GoTo Focused Delivery Program: Drive Systems
Drive Components - Choke
In connection with the mains chokes, converters and infeed power supply
units realize higher DC bus continuous power. They reduce the harmonics
in the line current while simultaneously preventing circuit feedback. When
using supply units with line regeneration, these components are always
required. This combination always complies to the permissible EMC values
for industrial networks stipulated by EN 61000-2-4.
For complete engineering and design information: GoTo GoTo www.boschrexroth-us.com/GoToDriveSystems
Features
• See Technical Data for more information.
Part Number Description Max. Quantity Shipment (Business Days)
R911379296 HNL01.1E-0100-N0220-A-480-NNNN 1 5 day(s)
R911307072 HNL01.1E-0170-N0146-A-500-NNNN 1 5 day(s)
R911306579 HNL01.1E-0200-N0125-A-480-NNNN 1 5 day(s)
R911306775 HNL01.1E-1000-N0012-A-500-NNNN 1 5 day(s)
R911306777 HNL01.1E-1000-N0020-A-500-NNNN 1 5 day(s)
R911315480 HNL01.1R-0300-C0180-A-480-NNNN 1 5 day(s)
R911379423 HNL01.2R-0540-C0094-A-480-NNNN 1 5 day(s)
R911306583 HNL01.1R-0590-C0065-A-480-NNNN 1 5 day(s)
R911306584 HNL01.1R-0980-C0026-A-480-NNNN 1 5 day(s)
R911335903 HNL01.2E-0400-N0051-A-480-NNNN 1 5 day(s)
USC00017/10.2021 | Electric Drives and Controls GoTo Bosch Rexroth Corporation 29
Resistor & Capacity Modules
GoTo Focused Delivery Program: Drive Systems
Drive Components - Resistor & Capacity Modules
In applications where high regeneration occurs over a relatively long period
of time, braking resistors are used. This is the case, when e.g. lowering
large loads or when braking high mass moments of inertia. Depending on
the braking power required there is a choice of compact brake resistors of
different power levels and designs for each converter.
For complete engineering and design information: GoTo GoTo www.boschrexroth-us.com/GoToDriveSystems
Features
• See Technical Data for more information.
Part Number Description Max. Quantity Shipment (Business Days)
R911299878 HLB01.1C-01K0-N06R0-A-007-NNNN 1 5 day(s)
R911299879 HLB01.1D-02K0-N03R4-A-007-NNNN 1 5 day(s)
R911308870 HLC01.1C-02M4-A-007-NNNN 1 5 day(s)
R911308869 HLC01.1D-05M0-A-007-NNNN 1 5 day(s)
R911306870 HLR01.1N-02K0-N15R0-A-007-NNNN 2 5 day(s)
R911305931 HLR01.1N-0300-N17R5-A-007-NNNN 2 5 day(s)
R911306921 HLR01.1N-04K5-N07R4-A-007-NNNN 2 5 day(s)
30 Bosch Rexroth Corporation Electric Drives and Controls GoTo | USC00017/10.2021
Master Encoder
GoTo Focused Delivery Program: Drive Systems
Drive Components - Master Encoder
Master Encoders GDS02.1 (Single-turn) / GDM02.1 (Multi-turn) are
designed to be used as rotary encoders within engineering and machine
constructions.
For application specic use of the encoders are devices with different
designs available.
For complete engineering and design information: GoTo GoTo www.boschrexroth-us.com/GoToDriveSystems
Features
• See Technical Data for more information.
Part Number Description Max. Quantity Shipment (Business Days)
R911323380 GDM02.1-2048-014V-H12,0 1 5 day(s)
R911323378 GDS02.1-2048-014V-H12,0 1 5 day(s)
