36 Bosch Rexro th Corporation Electric Drives and Controls Go T o | USC00017/10.2021 Pa r t Nu mbe r De sc rip tio n Ma x. Q u ant it y Sh ipm en t (Bu sin es s Days) R911344213 MSM031B-0300-NN-M5-MH0 3 5 day(s) R9113442…
USC00017/10.2021 | Electric Drives and Controls GoTo Bosch Rexroth Corporation 35
IndraDyn S - MSM Motors
GoTo Focused Delivery Program: Drive Systems
IndraDyn S - MSM Motors
Maintenance-free MSM motors are available in ve sizes rated at up to 750
W continuous mechanical power. These short-length motors feature high
power density and minimized ange dimensions, making them the ideal
choice in a wide range of application scenarios.
The IP54 motors come with an absolute encoder and optional holding
brake, and they can easily be connected to IndraDrive Cs power units with
a 3 AC 230 V line input.
For complete engineering and design information: GoTo www.boschrexroth-us.com/GoToDriveSystems
Features
• Torque up to 7.1 Nm
• Speed up to 5,000 rpm
• Multi-turn absolute encoder
• High dynamic performance
• High performance density
36 Bosch Rexroth Corporation Electric Drives and Controls GoTo | USC00017/10.2021
Part Number Description Max. Quantity Shipment (Business Days)
R911344213 MSM031B-0300-NN-M5-MH0 3 5 day(s)
R911344214 MSM031B-0300-NN-M5-MH1 3 5 day(s)
R911344215 MSM031C-0300-NN-M5-MH0 3 5 day(s)
R911344216 MSM031C-0300-NN-M5-MH1 3 5 day(s)
R911344217 MSM041B-0300-NN-M5-MH0 3 5 day(s)
R911344218 MSM041B-0300-NN-M5-MH1 3 5 day(s)
USC00017/10.2021 | Electric Drives and Controls GoTo Bosch Rexroth Corporation 37
Cables
GoTo Focused Delivery Program: Drive Systems
Cables
Motor Power- and Feedback Cable assemblies for IndraDrive C and
Cs drives with IndraDyn S motors in the GoTo program are offered in
multiple lengths and are completely assembled with connectors for easy
installation.
Interface/Communication cables for connection of control units and system
peripherals or start-up/commissioning via PC as described by type.
For complete engineering and design information: GoTo www.boschrexroth-us.com/GoToDrivesystems
Features
• See Technical Data for more information.
