USC00017/10.2021 | Electric Drives and Controls GoTo Bosch Rexroth Corporation 41
Frequency Converters (VFD)
EFC 3610 / 5610
GoTo Focused Delivery Program: Frequency Converters (VFD)
EFC 3610 / 5610
Rexroth EFC 3610 and EFC 5610 frequency converters are a compact,
affordable and energy-efcient drive solution for the 0.4 ... 160 kW (0.5-200
hp) performance range. Easy installation and commissioning allow for a
broad range of applications. With its V/f (V/Hz) control, the EFC 3610 is the
ideal drive for pumps and fans. The powerful SVC vector control in the EFC
5610 provides optimal torque characteristic and high starting torque for
special use. For safety-relevant applications, the EFC 5610 with STO (Safety
Torque Off ) option offers up to Cat. 4/PL e, SIL3 safety levels.
For complete engineering and design information: GoTo www.boschrexroth-us.com/GoToEFCx610
Features
• Compact and complete
• Integrated operator display panel for easy start-up
• Multi-Ethernet option
• Integrated brake chopper and mains lter
• Expandable with I/O, eldbus, and encoder option cards
• Detailed information: R999000430A
• Free IndraWorks Ds software tool download available via www.boschrexroth-us.com/efcx610
42 Bosch Rexroth Corporation Electric Drives and Controls GoTo | USC00017/10.2021
Part Number Description Max. Quantity Shipment (Business Days)
R912005717 EFC3610-0K40-3P4-MDA-7P-NNNNN-NNNN 3 5 day(s)
R912005718 EFC3610-0K75-3P4-MDA-7P-NNNNN-NNNN 3 5 day(s)
R912005719 EFC3610-1K50-3P4-MDA-7P-NNNNN-NNNN 3 5 day(s)
R912005720 EFC3610-2K20-3P4-MDA-7P-NNNNN-NNNN 3 5 day(s)
R912005721 EFC3610-3K00-3P4-MDA-7P-NNNNN-NNNN 3 5 day(s)
R912005722 EFC3610-4K00-3P4-MDA-7P-NNNNN-NNNN 3 5 day(s)
R912005091 EFC3610-5K50-3P4-MDA-7P-NNNNN-NNNN 2 5 day(s)
R912005092 EFC3610-7K50-3P4-MDA-7P-NNNNN-NNNN 2 5 day(s)
R912007793 EFC5610-0K40-3P2-MDA-7P-NNNNN-L1NN 3 5 day(s)
R912007272 EFC5610-0K40-3P4-MDA-7P-NNNNN-L1NN 3 5 day(s)
R912007794 EFC5610-0K75-3P2-MDA-7P-NNNNN-L1NN 3 5 day(s)
R912007273 EFC5610-0K75-3P4-MDA-7P-NNNNN-L1NN 3 5 day(s)
R912007795 EFC5610-1K50-3P2-MDA-7P-NNNNN-L1NN 3 5 day(s)
R912007274 EFC5610-1K50-3P4-MDA-7P-NNNNN-L1NN 3 5 day(s)
R912007796 EFC5610-2K20-3P2-MDA-7P-NNNNN-L1NN 3 5 day(s)
R912007275 EFC5610-2K20-3P4-MDA-7P-NNNNN-L1NN 3 5 day(s)
R912007798 EFC5610-4K00-3P2-MDA-7P-NNNNN-L1NN 3 5 day(s)
R912007277 EFC5610-4K00-3P4-MDA-7P-NNNNN-L1NN 3 5 day(s)
USC00017/10.2021 | Electric Drives and Controls GoTo Bosch Rexroth Corporation 43
EFC Accessories
GoTo Focused Delivery Program: Frequency Converters (VFD)
EFC Accessories
PROFIBUS card for connecting to a PROFIBUS master|Multi-Ethernet
card for connecting via Sercos III|PROFINET, EtherNet/IP, EtherCat or
Modbus TCP communication|Option module for housing two option
cards|I/O extension and relay card for more analog and digital ports|Shield
connection plate for easy EMC fastening of shielded lines
For complete engineering and design information: GoTo www.boschrexroth-us.com/GoToEFCx610
Part Number Description Max. Quantity Shipment (Business Days)
R912007360 FEAE02.1-EA-ETNN 5 5 day(s)
R912006052 FEAE02.1-EA-NNNN 5 5 day(s)
R912006134 FEAE03.1-ET-NNNN 5 5 day(s)
R912005787 FEAM02.1-EANN-NN-NNNN 5 5 day(s)
R912007672 FEAM03.2-001-NN-NNNN 5 5 day(s)
R912007673 FEAM03.2-002-NN-NNNN 5 5 day(s)
R912007623 FRKS0002/002,0 5 5 day(s)
R912007624 FRKS0002/003,0 5 5 day(s)
R911376069 USB CABLE 2.0A-MINI-B 5POL 6FT 5 5 day(s)
