Illustrated Parts Breakdown 1-105 Universal Stencil Assembly 990183 Parts Listing Key # Part # Description Quantity 1 002215 PLATE, UNIVERSAL ADAPTER 1 2 002216 RAIL, 3/4" ADAPTER 2 3 4T19 BAR , 26" UNIVERSAL A…
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-104
Universal Stencil Assembly 990183 (1 of 1)
990183
1
3
6
5
8
7
2,4
6
Illustrated Parts Breakdown
1-105
Universal Stencil Assembly 990183 Parts Listing
Key # Part # Description Quantity
1 002215 PLATE, UNIVERSAL ADAPTER 1
2 002216 RAIL, 3/4" ADAPTER 2
3 4T19 BAR, 26" UNIVERSAL ADAPTER 2
4 1000792 RAIL, SIDE 2
5 1/4-20 X 1 1/4" SHCS —
6 1/4-20 X 5/8" SHCS —
7 10-32 X 1/2" SHCS —
8 1/4-20 X 3/4" SHCS —
quantities are of entire assembly
NS not shown
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-106
Light Tower Assembly 990164 (1 of 1)
990164
3
1
4
4
9
8
5,10
7,10
6,10
2,12,13
11
14
15
16
17
15
16
