Illustrated Parts Breakdown 1-107 Light T ower Assembly 990164 Parts Listing Key # Part # Description Quantity 1 A2-421 POLE, LIGHT 1 2 P0512 CONNECTOR , HOOD 1 3 P0751 CABLE, SHIELDED 96.0 IN. 4 P0923-1 CO VER W/BASE 1 …
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-106
Light Tower Assembly 990164 (1 of 1)
990164
3
1
4
4
9
8
5,10
7,10
6,10
2,12,13
11
14
15
16
17
15
16
Illustrated Parts Breakdown
1-107
Light Tower Assembly 990164 Parts Listing
Key # Part # Description Quantity
1 A2-421 POLE, LIGHT 1
2 P0512 CONNECTOR, HOOD 1
3 P0751 CABLE, SHIELDED 96.0 IN.
4 P0923-1 COVER W/BASE 1
5 P0923-2 GREEN LENS 1
6 P0923-3 LENS, INDICATOR BANK LIGHT, RED 1
7 P0923-4 LENS, INDICATOR BANK LIGHT, ORANGE 1
8 P0923-5 ADAPTER, INDICATOR BANK MOUNT 1
9 P0923-7 GASKET, INDICATOR BANK BASE 1
10 P0923-8 BULB, LIGHT, INDICATOR BANK 3
11 P0976 GROMMET, #222 1
12 P3252 CONNECTOR, 9-PIN, D-SUB, CRIMP TYPE 1
13 P3603 CRIMP, PIN, 22-18 AWG 9
14 10-32 X 1/2" SHCS —
15 1/4-20 X 3/4" SHCS —
16 1/4" LOCK WASHER —
17 1/4" FLAT WASHER —
quantities are of entire assembly
NS not shown
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-108
Shutoff Valve Assembly AP20-51 (1 of 1)
19
18
21
1
23
2
9
9
5
13
13
15
15
10
4
4
20
12
20
14
8
7
19
11
23
3
16
6
25*
34
33
AP20_51
*SHOWN FOR MOUNTING REFERENCE
*
These parts are not included in this assembly
Front of
Printer
